Front and rear panel
TIMBRE SELECT/FORMANT HOLD key
If a Synth program using "layer" is selected,
this key allows you to chose which timbre
will be edited or sounded, or lets you edit
both timbres simultaneously (Sync).
If a Vocoder program is selected, this key
switches Formant Hold on, letting you hold
the tone currently produced by the vocoder
without continuing to speak into the mic.
TIMBRE SELECT 1 LED,
TIMBRE SELECT 2 LED
If a Synth program using Layer is selected,
the LED(s) will light to indicate which
timbre(s) will be edited. If a timbre is being
soloed, its LED will blink.
If a Vocoder program is selected, the 1 LED
will light if the formants are being held.
EDIT SELECT 1 dial,
EDIT SELECT 2 dial
These dials select the section to edit.
( p.12)
SYNTH/VOCODER 1 LED,
SYNTH/VOCODER 2 LED
These indicate whether the selected
program is a Synth or a Vocoder program.
If both the SYNTH/VOCODER 1 and 2
LEDs are lit, the Performance Edit function
is enabled.
If only one LED is lit, the EDIT SELECT
knob corresponding to the lit LED will be
the object of your editing. If the object of
editing has not been finalized, the LED will
blink.
ORIGINAL VALUE LED
This will light if the value of the parameter
currently being edited matches the value that is
stored in the program. ( p.13)
(This LED does not function for Performance
Edit.)
EDIT CONTROLS 1, 2, 3, 4, 5 knobs
These knobs edit the Performance Edit
parameters or the parameters of the section
selected by the EDIT SELECT 1 and 2
knobs. ( p.8, 9, 10)
Vocoder parameters
These are the parameters
for a Vocoder program.
Synth parameters
These are the parameters
for a Synth program.
3
