Korg Synthesizer/Vocoder micro Owner's Manual Page 24

Synthesizer/vocoder. Uploaded by: Da'Vidd Hollosy
Hide thumbs
WAVE
[Saw, Square, Triangle, Sine, Vox,
DWGS, Noise, Audio In]
Selects the waveform for oscillator 1.
Saw Wave (
):
This is a sawtooth wave. This wave-
form is shaped like the tooth of a
saw, and contains a rich overtone
spectrum.
You can use this to create numer-
ous instrumental sounds such as
string and brass sounds, or typical
analog synth sounds such as synth
bass or synth brass.
Square Wave (
):
This is a square wave. It has a rectan-
gular shape, and strictly speaking is
actually square only when the top and
bottom of the waveform have the same
width (a "pulse width" of 50%). If the
pulse width is other than 50%, this is
also called a pulse wave.
A square wave is used for woodwind
sounds such as clarinet, and for
wooden percussion sounds. A pulse
wave is used for plucked-string
sounds and reed-type sounds.
18
3. OSC1
(Oscillator 1)
The oscillator generates the waveform that is the basis of the sound.
The timbre has two oscillators. The settings in this section are for oscillator 1. "WAVE" (knob 1) selects the basic waveform for oscillator 1,
and "CONTROL 1" (knob 2) and "CONTROL 2" (knob 3) modify the waveform. For example if you set "WAVE" to Saw (
"CONTROL 1" value will modify the sound, changing the waveform as shown in figure 3-1. Adjusting "CONTROL 2" will apply LFO1
modulation to the waveform specified by "CONTROL 1," producing additional change.
CONTROL 1
[0...127/– – –]
CONTROL 2
Adjusts a parameter specific to the
Adjusts a parameter specific to the
selected waveform.
selected waveform.
CONTROL 1 has no effect if
"WAVE" is set to DWGS.
CONTROL 1
[0...127]:
CONTROL 2
Adjusting this value will modify the
LFO1 is used to apply modulation
waveform.
to the waveform specified by
A setting of 0 will produce a con-
"CONTROL 1." The "CONTROL 2"
ventional sawtooth wave, and a set-
setting specifies the depth of the
ting of 127 will produce a sawtooth
modulation produced by LFO1.
wave one octave higher.
For example by setting LFO1
( Figure 3-1)
"WAVE" to Triangle (
justing the LFO speed, you can pro-
duce a detune-like effect.
CONTROL 1
[0...127]:
CONTROL 2
Adjusts the pulse width. A setting
LFO1 is used to apply PWM (pulse
of 0 produces a pulse width of 50%
width modulation)*
(square wave), and a setting of 127
width specified by "CONTROL 1."
produces a pulse width of 0% (there
The "CONTROL 2" setting specifies
will be no sound). The sound will
the depth of the modulation pro-
become "harder" as you adjust this
duced by LFO1. For example by
parameter toward 0%.
setting LFO1 "WAVE" to Triangle
( Figure 3-2)
(
speed, you can add depth to the
sound.
— SYNTH/VOCODER
[0...127/1...64]
[0...127]:
Figure 3-1
0
) and ad-
[0...127]:
Figure 3-2
3-1
to the pulse
0
) and adjusting the LFO
), adjusting the
63
127
*3-1: PWM
Pulse Width Modulation refers to the
use of a separate signal to vary the
pulse width over time. On the
microKORG, you can use PWM to
63
127
modify the tone via LFO1, or via Vir-
tual Patch from modulation sources
LFO2, Filter EG, or Amp EG.
