8. AMP
These parameters adjust the volume. "LEVEL" (knob 1) specifies the volume of the internal sound source (OSC 1, NOISE) for the carrier.
"KBD TRACK" (knob 4) specifies how keyboard tracking will affect the volume, and "DISTORTION" (knob 3) specifies whether the sound
will be distorted.
The "DIRECT LEVEL" (knob 2) specifies the output volume level of the sound that is input from AUDIO IN 1.
LEVEL
[0...127]
DIRECT LEVEL
Specifies the volume level of the in-
Specifies the volume level of the au-
ternal tone generator (OSC1,
dio that is output directly from
NOISE) for the carrier.
AUDIO IN 1.
9. AMP EG
The "9. AMP EG" parameters are the same as for a synth program ( p.28). They specify the shape of the AMP EG, which creates time-variant
change in the volume of the internal carrier sound source (OSC 1, NOISE). Virtual Patches are not available when using vocoder programs.
10. LFO 1, 11. LFO 2
The "10. LFO1" and "11. LFO2" parameters are the same as for a synth program ( p.29). Cyclic change produced by the LFO can apply
modulation to the internal carrier sound source (OSC 1, NOISE). Virtual Patches are not available when using vocoder programs.
— VOCODER
[0...127]
DISTORTION
[OFF, ON]
Specifies whether distortion will be
applied to the OSC 1, NOISE, and
AUDIO IN 2 signal.
OFF (
):
Distortion is off
ON (
):
Distortion is on
— SYNTH/VOCODER
— SYNTH/VOCODER
KBD TRACK
[-63...63]
Specifies how keyboard tracking
will affect the volume.
With positive (+) settings, the vol-
ume will increase as you play above
the note C4 on the keyboard, and
will decrease as you play below C4.
With negative (-) settings, the vol-
ume will decrease as you play
above C4 on the keyboard, and will
increase as you play below C4.
Keyboard Track operates ac-
cording to the pitch that is con-
trolled by pitch bend and the
"TRANSPOSE" setting. It is not
affected by pitch changes pro-
duced by vibrato or Virtual
Patch.
37
