Messages transmitted and received by the microKORG
Control 2 values when OSC 1 Wave = DWGS
When the synth parameter OSC 1 "WAVE" is set to DWGS, the "CONTROL 2" (knob 3 )
will select the DWGS waveform. The value of the control change transmitted/received
by operating the "CONTROL 2" (knob 3 ) corresponds to the parameter value as
follows.
Value Value
DWGS Wave
(transmitted, received) (transmitted, received)
0, 1 1 64, 65
2, 3 2 66, 67
4, 5 3 68, 69
6, 7 4 70, 71
8, 9 5 72, 73
10, 11 6 74, 75
12, 13 7 76, 77
14, 15 8 78, 79
16, 17 9 80, 81
18, 19 10 82, 83
20, 21 11 84, 85
22, 23 12 86, 87
24, 25 13
88, 89
26, 27 14 90, 91
28, 29 15 92, 93
30, 31 16 94, 95
32, 33 17 96, 97
34, 35 18 98, 99
36, 37 19 100, 101
38, 39 20 102, 103
40, 41 21 104, 105
42, 43 22 106, 107
44, 45 23 108, 109
46, 47 24 110, 111
48, 49 25 112, 113
50, 51 26
114, 115
52, 53 27 116, 117
54, 55 28 118, 119
56, 57 29 120, 121
58, 59 30 122, 123
60, 61 31 124, 125
62, 63 32 126, 127
DWGS Wave
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
OSC 2 Semitone values
The value of the control change transmitted/received by operating OSC 2
"SEMITONE" (knob 3 ) of a synth program corresponds to the parameter value as
follows.
Value (transmitted, received) OSC 2 Semitone Value (transmitted, received)
0...2 –24
66, 67
3...5 –23 68...70
6, 7 –22
71...73
8...10 –21 74, 75
11...13 –20 76...78
14, 15 –19
79, 80
16...18 –18 81...83
19, 20 –17
84...86
21...23 –16 87, 88
24...26 –15 89...91
27, 28 –14
92...94
29...31 –13 95, 96
32, 33 –12
97...99
34...36 –11
100, 101
37...39 –10 102...104
40, 41 –9
105...107
42...44 –8 108, 109
45...47 –7 110...112
48, 49 –6
113, 114
50...52 –5 115...117
53, 54 –4
118...120
55...57 –3 121, 122
58...60 –2 123...125
61, 62 –1
126, 127
63...65 0
"SYNC NOTE" value when LFO 1/2 or DELAY "TEMPO SYNC" = ON
If "TEMPO SYNC" is ON, the parameter that is set by the LFO 1/2 "FREQUENCY"
(knob 4 ) or the DELAY "DELAY TIME" (knob 3 ) will change to "SYNC NOTE." In this
case, the value of the control change message transmitted by knob operations (or
received) will correspond to the parameter value as shown below.
Value (transmitted, received) LFO Sync Note DELAY Sync Note
0...8 1/1 1/32
9...17 3/4 1/24
18...25 2/3 1/16
26...34 1/2 1/12
35...42 3/8 3/32
43...51 1/3 1/8
52...59 1/4 1/6
60...68 3/16 3/16
69...76 1/6 1/4
77...85 1/8 1/3
86...93 3/32 3/8
94...102 1/12 1/2
103...110 1/16 2/3
111...119 1/24 3/4
120...127 1/32 1/1
OSC 2 Semitone
+1
+2
+3
+4
+5
+6
+7
+8
+9
+10
+11
+12
+13
+14
+15
+16
+17
+18
+19
+20
+21
+22
+23
+24
