Specifications and options

Tone generator system: Analog modeling synthesis system
• Synth programs:
Number of timbres:
maximum 2 (when using Layer)
Maximum polyphony: 4 voices
Structure:
2 oscillators + noise generator: sawtooth wave, square wave,
triangle wave, sine wave, Vox wave, DWGS x 64, Noise, Audio
In (8 types)
PWM function, OSC Sync function, Ring Mod. function, OSC
Sync + Ring Mod. function
Multimode filters: -24 dB/oct LPF, -12 dB/oct LPF, -12 dB/oct
BPF, -12 dB/oct HPF (4 types)
Filter EG, Amp EG, LFO1, LFO2 (LFO: six waveforms,
synchronizable to arpeggiator or external MIDI clock)
• Vocoder programs:
Maximum polyphony: 4 voices
Structure:
8 channel vocoder, adjustable level and pan for each channel,
Formant Shift function
1 oscillator + noise generator (8 types)
Filter EG, Amp EG, LFO1, LFO2, (LFO: six waveforms,
synchronizable to arpeggiator or external MIDI clock)
Keyboard:
37 notes (mini keyboard, velocity sensitive, no aftertouch)
Effects:
Modulation effect: flanger/chorus, phaser, ensemble (3 types),
Delay: stereo, cross, L/R (3 types), Equalizer
Arpeggiator: UP, DOWN, ALT1/2, Random, Trigger (6 types), Step Arpeggiator
function
Programs:
total 128 programs (A/B side x 8 banks x 8 programs)
Inputs
• AUDIO IN 1 CONDENSER jack (with MIC/LINE switch)
Connector +5V mini-phone jack
AUDIO IN 1 (LINE)
Input impedance:
39 [k ]
Maximum input level:
-3.5 [dBu] (VOLUME 1: Max)
AUDIO IN 1 (MIC)
Input impedance:
22 [k ]
Maximum input level:
-33 [dBu] (VOLUME 1: Max)
• AUDIO IN 1 DYNAMIC jack (with MIC/LINE switch)
Connector
1/4" phone jack (unbalanced)
AUDIO IN 1 (LINE)
Input impedance:
39 [k ]
Maximum input level:
-3.5 [dBu] (VOLUME 1: Max)
Input impedance:
600 [ ]
AUDIO IN 1 (MIC)
Input impedance:
22 [k ]
Maximum input level
-33 [dBu] (VOLUME 1: Max)
Input impedance:
600 [ ]
• AUDIO IN 2 LINE jack
Connector
1/4" phone jack (unbalanced)
Input impedance:
39 [k ]
Maximum input level
-3.5 [dBu] (VOLUME 2: Max)
Input impedance:
600 [ ]
Outputs
• L/MONO, R jacks
Output impedance:
1.1 [k ] (MONO: 550 )
Maximum output level: +0.0 [dBu] or more
Load impedance:
100 [k ]
• Headphone jack
Output impedance:
10 [ ]
Maximum output level: 35 [mW]
Load impedance:
33 [ ]
MIDI:
IN, OUT, THRU connectors
Display:
3-digit x 1 line eight-segment LED
Power supply: when using AC adaptor: DC9V, 6.5 W
when using batteries: six AA batteries, 9 V
Battery life:
approximately 4 hours or more (when using alkaline batteries)
Dimensions:
524 x 232 x 70 mm / Inches: 20.63" x 9.13" x 2.76" (W x D x H)
Weight:
2.2kg / 4.85 lbs. (without batteries and included microphone)
Included items: condenser microphone, AC adaptor (DC9V)
*
Appearance and specifications of this product are subject to change without
notice.
67
