centormail Operator Manual
Calibration
Print heads correctly aligned
Print heads not correctly aligned
The print heads are calibrated after the
exchange procedure. See the display to
monitor the process. Please wait until the
calibration has finished.
Cleaning
After calibration, the print heads are
cleaned. The cleaning procedure is auto-
matically performed.
Adjusting the print heads
centormail continues with the print head
adjustment procedure: It tells you to posi-
tion a letter.
• Position an empty envelope for the test
print.
centormail generates the test imprint.
• On the test imprint, determine the num-
bers next to which
– the horizontal bars are best aligned
to each other and
– the vertical bars are best aligned to
each other.
If the horizontal and vertical bars form a
straight line below number 5, the print
heads are correctly aligned.
• Press F
dure.
If the horizontal and vertical bars do not
form a straight line below number 5:
• Press C
adjustment procedure.
to complete the proce-
INISH
to proceed with the
ONTINUE
