Post Base Vision
Servicedocumentation
Post Base Vision - Whats new?
-
Sicpa printhead with lifter module
-
print module with green LED (inserted & ok) and new PDB
-
modified drawer and ink awamp
-
WiFi
-
Display mit control buttons (Volume, display angle [panning], brightness)
-
speaker
-
scale tray with illuminated FP logo
-
N-PSD
-
no customer batterie
-
mainboard with Vybrid Prozessor (~PB100)
-
illuminated infeeding (gate with sliding sheet)
-
power button (white LED)
-
several housing parts / Cover Sets
-
speed values: 35 / 50 / 70 / 85
-
no navigator (portal)
Note:
Working on electronic modules requires ESD protection!
j.tolksdorf@francotyp.com
vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24
img_3717_
Stand 21.12.2018 / 24.1.19
Page
1
/ 27
Advertisement
Related Manuals for FP Post Base Vision
Summary of Contents for FP Post Base Vision
- Page 1 Post Base Vision Servicedocumentation Post Base Vision - Whats new? Stand 21.12.2018 / 24.1.19 Sicpa printhead with lifter module print module with green LED (inserted & ok) and new PDB modified drawer and ink awamp WiFi Display mit control buttons (Volume, display angle [panning], brightness)
- Page 2 Post Base Vision Servicedocumentation Print System Sicpa only 1 printhead adjusting of printunit useless new printunit with lifter module CP function „on board“ (no such chip) filling levels: 10 / 20 / 40 ml img_3709_ img_3702_ img_3860_ img_3858_ inserting the printhead Img_3924.mov...
- Page 3 Post Base Vision Servicedocumentation Drawer 1. Slot for spitting is modified due to the shape of print SICPA head 2. The upper black cover has a break-out recess (for Sicpa), so that the plastic part can also be used for the Classic drawer. That means there are 2 different drawers (Classic & Vision).
- Page 4 Post Base Vision Servicedocumentation upper letter tray 1. upper letter tray: opening for the Sicpa printhead is enlarged 2. infeeding gate with sliding sheet metal gets illumination (3 LED) (LEDs flashing, if drawer is not in place) img_3836_ Page / 27 j.tolksdorf@francotyp.com...
- Page 5 Post Base Vision Servicedocumentation N-PSD green battery with enlargend capacity (ext. batt. not longer needed) not compatible to any other PostBase img_3871_ battery cover 1. the old battery cover clip is not needed any longer. img_3838_ Page / 27 j.tolksdorf@francotyp.com...
- Page 6 Post Base Vision Servicedocumentation Service case: remove printhead manually The print system Sicpa contains of 1 cartridge and the sealing by a powered lifter module. If the menue “exchange cartridges” is not available, there is a manual exchange possible. But the procedure is changed;...
- Page 7 Post Base Vision Servicedocumentation ink swamp The ink swamp has a larger opening (adaptation to Sicpa). img_3841_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 8 Post Base Vision Servicedocumentation MTS modul The MTS is new and can be easily removed and replaced from the buttom side. (Sealing cap, opening, wiper) It is recommended to lift the print unit before removing the MTS! img_3846_ / Video remove MTS IMG_3845.MOV...
- Page 9 Post Base Vision Servicedocumentation Removal of the lifting module The lifting and lowering seals (or unseals) the Sicpa printhead and is powered. The manual procedure of mooving the the print unit is changed. Note 2. lift the printing unit manually (Insert the stylus through the sump door & turn ¼...
- Page 10 Post Base Vision Servicedocumentation img_3853_ img_3854_ see note above! Open cartrige door (Stylus) Remove hood (unplug X43 to speaker & 6 screws T20) img_3852_ Remove display unit (X9, X30, X16 & 1 screw.) img_3872_ Remove label dispenser (X24 & 1x screw)
- Page 11 Post Base Vision Servicedocumentation if necessary, remove infeed plate with LED Remove letter transport X16 to encoder & 2 possibly infeed plate board (= gate with sliding sheet metal) screws at the front ( X44 & 1 screw) Lift the print assembly (use the Stylus!) and moove it to ~1cm ( 0,4”)before 1...
- Page 12 Post Base Vision Servicedocumentation - unscrew both rods (SW 8mm) and remove print unit img_3890_ Lift the machine out of the lower housing Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 13 Post Base Vision Servicedocumentation Removal of the lifting module: Unplug X37 + X38 at the mainboard and thread out the wires Video: remove MTS IMG_3845.MOV Remove MTS (unclip from the bottom) unscrew bracket serviceposition (2 srews), unclip the pin underneath is the interlock service...
- Page 14 Post Base Vision Servicedocumentation remove the expansion pin img_3903_ Unclip 2 locking noses (plier) img_3904_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 15 Post Base Vision Servicedocumentation press lifting module up … … …and remove from the top img_3906_ img_3905_ Inserting the lifting module - first insert the lifting module on the letter transport side and minimize the play in the direction of the letter path...
- Page 16 Post Base Vision Servicedocumentation Mainboard connectors mainboard connectors 0001.png Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 17 Post Base Vision Servicedocumentation exchange of Pendriverboard (PDB) ESD protection required! First remove the print module! Unhook the spring img_3908_ Unscrew 2 screws Img_3910_ Pull both pins img_3912_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 18 Post Base Vision Servicedocumentation Separate the housings Img_3913_ Thread out flat cable unscrew the cover of the PDB IMG_3914_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 19 Post Base Vision Servicedocumentation IMG_3917_ Img_3919 IMG_3920_.png IMG_3921_a.png Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 20 Post Base Vision Servicedocumentation Display & Motor assembbly img_3810_ Remove display unit (X9, X30, X16 & 1 screw) Unscrew 1 screw img_3872_ Unclip pivot bearings on right and left (pay attention to any washers that may be present img_3876_ Page / 27 j.tolksdorf@francotyp.com...
- Page 21 Post Base Vision Servicedocumentation IMG_3877_ swivel drive has a slide clutch (manual swivel), a spring to minimize the play a a screw for fixation Unhook spring, unscrew, remove engine Img_3878_ Img_3884_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 22 Post Base Vision Servicedocumentation Note It is important to find the right totth flank position. When installing, do not tighten the screw first insert the display tighten the screw Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 23 Post Base Vision Servicedocumentation Wifi Push WiFi holder to the right Pull WiFi modul Img_3870_ img_3923_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 24 Post Base Vision Servicedocumentation Scale The electronic board is tilted because of the underlying illumination of the FP logo in the tray exchange of the LED Unscrew 3 screws img_3943 img_3922_ LED holder LED replacement: turn until the flat side points towards the latch...
- Page 25 Post Base Vision Servicedocumentation img_3944_ Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 26 Post Base Vision Servicedocumentation more new components img_3731_ Power button Scale tray img_3738_ img_3750_ cover sets: stahlgrau / steel gray marmorweiß/ marble white sahara-gold rose kaschmir blau/ cashmere blue img_3744_a Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
- Page 27 Post Base Vision Servicedocumentation IMG_3747_ img_3742 018_.png Page / 27 j.tolksdorf@francotyp.com vision 0003 en.docx !!Company confidential!! Revision 19 / 01 / 24...
