D.1.2 Operation Info Screen - Image Access WideTek 36C Manual

D.1.2 Operation Info Screen
In the section Device Information
It shows various scan counters and elapsed time described in the following table.
The following table gives a brief description.
Field
Total Scan Count
Total Power Up Cycles
Total Operating Time
Lamp Operating Time
Remaining Lamp Operating
Time
To return to the USER screen (Picture 73), click the button Back to Main Menu or click
on the "Return" button in your browser.
To return to the Login screen (Picture 72) click the button
Click the button Launch Scan Application to switch directly to the main screen of the
integrated S2N user interface.
Manual
the button Operation Info opens the following list.
Picture 76: Operation Info screen
Description
The total number of scans performed since the scanner left
the factory. Each CCD scan cycle is counted, regardless of
it being a pre-scan or a full scan.
The total number of power up cycles performed since the
scanner left the factory. This function counts the start/stop
button invoked cycles only.
The total operating time since the scanner left the factory.
This is the on-time only, standby time does not count.
The total lamp operating time since the scanner left the
factory.
The typical remaining lifetime of the lamps. With normal
working conditions the lamp life is sufficient for the lifetime
of the device.
Setup Menu
Page 67
