Powering up the WideTEK
A.10.1
The main power switch is found at the back of the scanner.
Picture 7 shows the position of power supply connector and main power switch.
After connecting the scanner to the external power supply, switch the main power switch
to position I. When the main power switch is in position I, the on/off button will be
illuminated and the scanner is in standby mode.
While using the WideTEK
Note: only be powered up and down by the on/off button
at the right side of the front panel!
Starting the WideTEK
A.10.2
Push the red illuminated on/off button to start the scanner.
The button illumination changes to blue.
The scanner starts with self-test routines and verifies all system components. Status
messages will be displayed on the TFT flat screen (if connected) and on the touchscreen.
At the end of the start-up sequence, the touchscreen displays the start screen.
Switching the WideTEK
A.10.3
Always turn off the WideTEK
Note:
the right side of the front panel!
The main
WideTEK ®
disconnected from the external power supply.
To turn off the WideTEK
seconds. While pressing the button, a "click" sound is audible.
The content of the TFT flat screen and the touchscreen changes and display the
message: Going to shut down now ...
Finally the TFT flat screen and the touchscreen switch off and the on/off button will be
illuminated red.
A.10.4

The Help Function

To support the user when working with the WideTEK
into the touchscreen menus. A Question Mark (?) symbol in the bottom line of the
touchscreen activates the help function.
After touching the question mark, an additional window opens in the touchscreen and
shows information about the menu items of the selected menu.
Touching the OK button will close the additional window.
Manual
® 36C
®
® 36C
power switch should
36C
is in stand-by mode and before the scanner is
36C, press and hold the on/off button for at least three
®
® 36C
in work conditions, it should
36C
from Standby Mode
® 36C
to Standby Mode
scanner with the on/off button at
only be used
® 36C, a help function is integrated
when the
Page 23
