Overview
Chapter
Copier Parts and Accessories (Options)
4
3
2
1
20- Bin Staple Sorter
1
1
Sort Bins (1st to 20th)
2
2
Non-Sort Bin
3
3
Lock Release
4
4
Staple Cover:
Reversing Automatic Document Feeder (RADF)
5
5
Document Exit Tray
6
6
Document Feed Tray
Extender
7
7
Document Feed Tray
8
8
Document Guide Plate
9
9
Single Feed Tray
14
5
6 7
: Hold sorted or batched copies, each capable of
holding up to 50 sheets.
: Holds up to 100 copies fed out in the Non-Sort mode.
: Press to unlock the Sorter from the copier for clearing a
misfed sheet of paper or other service job.
: Open to replace staples cartridge.
: Receives originals that are automatically ejected from
Document Feeder.
: Pull out when loading large-size originals.
: Load the originals face up on this tray.
: Slide the plate as necessary to the size of the originals.
: Place a single sheet of originals on the tray to make a
copy or copies of it. p.28
