imagistics DL155 User Manual

Congratulations on your choice of the DL155/185 Multi-function Copier!
The DL155/185 is a CUSTOMER INSTALLABLE unit that does not require
a service technician to set-up. However, if a service technician
installation is required, call 1-800-243-5556 for assistance.
Please refer to the following set-up instructions for the easy installation
of this unit.
Install the copier as follows:
2
1
Unpack the machine
from the package.
1 Copier
2 Power cord
3 Original holder
(DL155 copier),
• User's Manual
3
Open the multi-bypass.
7
Pull the drawer out.
11
Lift open the Document Feeder and
remove the sheet on the platen.
CAUTION
3
Two people are required to move the
copier. Stand on the front and rear
sides of the copier and hold it tightly
by the handles on the sides. If you
stand on the right and left sides of
the copier or hold it by the drawer,
you may damage the copier or injure
1
yourself or someone else.
4
Open the left cover.
8
Remove the tapes and two pads.
Close the drawer.
12 Open the front cover.
DL185
DL155
2
5
Remove the tapes.
9
Remove the tapes and two
scanner pins.
IMPORTANT!
Do not load paper before the main
switch is turned on and copying is
enabled. If you do, a paper misfeed may
occur when the main switch is turned on.
13
Remove the cardboard pad
on the left side.
This product is sold and
supported by:
Imagistics International Inc.
www.imagistics.com
Remove the tapes.
DL185: 9 pieces
DL155: 13 pieces
6
Lift the two fixing section
release levers.
10 Store the removed scanner pins
by securing them on the inside
of the front cover. These pins
are required whenever the
copier is moved.
The storing locations for the
scanner pins are marked inside
the front cover.
14
Tear the blue tape and gently
pull the clear strip out of the
machine.
OVER
