Overview
Chapter
Copier Parts and Accessories (Inside)
2
1
10
1
1
Toner Bottle Holder
2
2
Toner Bottle
3
3
Original Width Scale
4
4
Original Length Scale
5
5
Original Pad
6
6
Original Glass
7
7
Corona Cleaning Lever
8
8
Dehumidifier Switch
9
9
Transport Release
Lever M2
10
10
Misfeed Removal Knobs : Use to clear a misfeed sheet of paper. p.115
11
4
3
9
8
: Swing open to replace Toner Bottle.
: Contains Printpowder™ Toner. Replace when empty. p.108
: Use to correctly position original.
: Use to correctly position original.
: Holds the original in position on the Original Glass.
: Place originals face down on glass to copy
: Operate lever to clean the Corona if unwanted lines
appear on copies.
: Do not use this switch. For Service use only.
: Swing down to release the Transport and remove misfed
paper.
5
6
7
10
