Overview
Chapter

Using the Touch Panel

When you turn ON the Power Switch the Basic screen as shown below appears on the Touch Panel. It displays messages,
graphics, currently set functions, available functions to choose from, and the copier status.

How the Screen is Organized

1
1 Supplementary Function Keys
4
4 Set Function Display
1
1 Supplementary Function Keys
Example: Auxiliary Function
18
The Auxiliary, Finishing, Original to.
Copy, and Basis keys are displayed.
When any of these supplementary
function screen appears.
*Touching Basics returns you to the
Basic screen.
2
2
Message Display
3
3 Basic Function/Key
