Ethernet ports are labeled NET0, NET1, NET2, and NET3. The Ethernet interfaces
■
operate at 10 Mbps, 100 Mbps, and 1000 Mbps.
Connection Type
Ethernet
Fast Ethernet
Gigabit Ethernet
USB Ports: USB ports support hot-plugging. You can connect and disconnect USB
■
cables and peripheral devices while the server is running, without affecting server
operations.
■
■
AC power cables: Do not attach power cables to the power supplies until you have
■
finished connecting the data cables, and have connected the server to a serial
terminal or a terminal emulator (PC or workstation). The server goes into Standby
mode and the ILOM service processor initializes as soon as the AC power cables
are connected to the power source. System messages might be lost after 60 seconds
if the server is not connected to a terminal, PC, or workstation.
Related Information
"Confirming Specifications" on page 5
■
"Handling Precautions" on page 13
■
"Rear Panel Cable Connections Reference" on page 24
■
36 SPARC T4-4 Server Installation Guide • May 2014
The service processor serial management port (labeled SER MGT) uses an RJ-45
cable and is always available. This port is the default connection to the ILOM
service processor.
The service processor network management port (labeled NET MGT) is the
optional connection to the ILOM service processor. The NET MGT port is
configured to use DHCP by default. To set a static IP address, see
Static IP Address to the SP" on page
management port uses an RJ-45 cable for a 10/100 BASE-T connection. This
port does not support connections to Gigabit networks.
IEEE Terminology
10BASE-T
100BASE-TX
1000BASE-T
You can only perform USB hot-plug operations while the OS is running. USB
hot-plug operations are not supported when the server ok prompt is displayed
or before the server has completed booting.
You can connect up to 126 devices to each of the four USB controllers, for a total
of 504 USB devices per server.
50. The service processor network
Transfer Rate
10 Mbit/sec
100 Mbits/sec
1000 Mbit/sec
"Assigning a
