User Guide CCM-BOOGIE • High Performance Core

Microprocessor

The CCM-BOOGIE is designed for use with Core
(code name Penryn). These includes also the Ultra Low-Voltage (ULV) and the Low-Voltage (LV)
TM
Core 2 Duo processors as listed below. The processors are housed in a Small Form Factor (SFF) Micro
FC-BGA package for direct soldering to the PCB, i.e. the CPU chip cannot be removed or changed by
the user.
The processors supported by the CCM-BOOGIE are running at FSB clock speeds of 800MHz or
1066MHz. The internal Core
frequency by a variable value. The multiplier is chosen by currently required performance and the
actual core temperature. To further lowering the power dissipation, the processor is able to halve its
FSB clock speed dynamically. This technology is called Enhanced Intel SpeedStep®.
Power is applied across the CompactPCI connectors J1 (3.3V, 5V). The processor core voltage is
generated by a switched voltage regulator, sourced from the 5V plane. The processor signals its
required core voltage by 7 dedicated pins according to Intels IMVP-6 voltage regulator specification.
Processor Number
of Cores
ULV Celeron M
722
ULV Core 2 Duo
SU9300
LV Core 2 Duo
SL9400
SV Core 2 Duo
SP9300
© EKF
TM
2 Duo processor speed is achieved by multiplying the host bus
45nm Processors Supported
Speed Host
min/max Bus
[GHz] [MHz]
1 1.20/1.20 800
2 0.80/1.20 800
2 0.80/1.86 1066
2 0.80/2.26 1066
TM
2 Duo 3U CompactPCI
TM
2 Duo processors manufactured in 45nm technology
L2 TDP Die Temp
Cache [W] [°C]
[MB]
1 5.5 0-100
3 10 0-105
6 17 0-105
6 25 0-105
-18-
®
CPU Board
CPU ID Stepping sSpec
TBD TBD
10676h M-0 SLB5Q
10676h C-0 SLB66
10676h C-0 SLB63
TBD
