User Guide • SC1-ALLEGRO •
On-Board Connectors & Sockets
J-EXPT Utility EXPansion Interface Connector (LPC, USB, HD Audio, SMBus), available either
1)
J-EXPB from top (T) or bottom
J-HSE High Speed Expansion Connector (3 x SATA, 4 x USB), interface to optional low
profile mezzanine module or side board
J-PCIE PCI Express® Expansion Interface Connector, interface to optional side board
J-SDVO Digital Display Interface Connector (SDVO/DisplayPort)
CompactPCI
P1
CompactPCI
P2-P4
CompactPCI
P5
CompactPCI
P6
SODM1 204-pin DDR3 ECC Memory Module SDRAM PC3-12800 Socket (ECC SODIMM)
XDP CPU Debug Port
1)
Connector populated on customers request only

Pin Headers

P-FPH Pin header suitable for Front Panel Handle switch cable harness
P-ISP PLD glue logic device programming connector, not populated

Jumpers

DS-P Switches to configure link width and speed on J-PCIE
P-GP Jumper to reset UEFI BIOS Setup to EKF Factory Defaults
P-MFG Jumper to enter Manufacturing Mode, not populated
P-RTC Jumper to reset RTC circuitry (part of PCH), not populated
© EKF
CompactPCI
1)
(B) of the board, interface to optional side board
®
Serial Type A Connector
®
Serial Type B Connectors
®
Serial Type C Connector
®
Serial Type D Connector
1)
® Serial
CPU Board • Intel® i7-3xxx Processor
-14- ekf.com
