GridVminRecT(V)
GridVRecT(S)
GridF.Max1(Hz)
FmaxTripT1(S)
GridF.Min1(Hz)
FminTripT1(S)
GridF.Max2(Hz)
FmaxTripT2(S）
GridF.Min2(Hz)
FminTripT2(S)
GridFmaxRecT(Hz)
of Max. grid voltage
Recovery threshold value
of Min. grid voltage
Recovery time of grid
voltage protection
Protection threshold value
of Level 1 Max. grid
frequency
Trip time of Level 1 Max.
grid frequency
Protection threshold value
of Level 1 Min.
frequency
Trip time of Level 1 Min.
grid frequency
Protection threshold value
of Level 2 Max. grid
frequency
Trip time of Level 2 Max.
grid frequency
Protection threshold value
of Level 2 Min.
frequency
Trip time of Level 2 Min.
grid frequency
Recovery threshold value
of Max. grid frequency
72
{0, 362.6, 480.0}
{0, 300.00, 600.00}
{50.00,51.50, 65.00}
{0, 0.10, 600.00}
grid {45.00, 47.5, 60.00}
{0, 0.10, 600.00}
{50.00, 51.50, 65.00}
{0, 0.10, 600.00}
grid {45.00, 47.50, 60.00}
{0, 0.10, 600.00}
{49.00, 50.05, 65.00}
