The main operation interface of LCD screen has 5 menus, i.e. "1 OP. Info",
"2 Alarm", "3 History", "4 Setting" and "5 Dispatch". The users may select
options with UP and DOWN, and then press ENT to confirm selection. The
users can return to the default indication interface by pressing ESC.

5.4.1 Operation information

When the cursor moves to "1 OP. Info" in the main screen, you should
press ENT to select the operation information as shown in Figure 5-8. Check
the information by pressing UP and DOWN. Return to the previous menu by
pressing ESC.
Figure 5-8 Operation information indication (PV independent mode)
Figure 5-7 Main menus on the LCD screen
1 OP.Info
EDay 23.5kWh
PDayPk 19kW
DayT 12 .1 h
Uab 400.2V
Ubc 400.9V
Uca 399.7V
Freq 50.0Hz
Ia 13.9A
Ib 14.1A
Ic 13.1A
Tmod 78.2C
Tamb 50 C
Upv 1 360.0V
Ipv1 14.7A
Upv 2 360.4V
Ipv2 14.3A
Sac 17KVA
Pac 16.7kW
