Model Name
DC Input
Nominal DC Input Power
Max. DC Input Power for
each MPPT
Max. DC Input Voltage
Operating DC Input Voltage
Range
Start-up DC Input Voltage /
Power
Nominal DC Input Voltage
Number of MPP Trackers
MPPT Voltage Range
Max. Input Current
Isc PV(absolute max)
Max. inverter backfeed
current to the array
Number of DC Inputs
DC Disconnection Type
AC Output
Rated AC Output Power
Max. AC Output Power
Rated Output Voltage
Output Voltage Range
Grid Connection Type
Max AC Output Current
AC Inrush Current
Maximum Output Fault
Current
1
Exceeding the Max. DC Input Voltage may cause permanent damage to the equipment.
2
The Output Voltage Range may differ according to specific grid standard.

Chapter 8 Technical Data

SCA20KTL-DO
1
2
99A Peak@203.4us
CPS
21kW
12kW
1000Vdc
300-900Vdc
330V/300W
635Vdc
400-800Vdc
2x 27A
2x 41A
4 stringsx2
Integrated DC switch
20kW
20kW
400/230Vac
320-460Vac
3Φ/ N / PE
32A
L-N/PE 100A Peak@320ms,
56.6A RMS@20ms
L1/L2/L3 158A Peak@992ms,
98
CPS SCA25KTL-DO
26kW
14kW
2
2x 32A
2x 48A
0 A
25kW
25kW
40A
149A Peak@211us
