step 6, Figure 3-13)
Tool: No.2 Phillips head screwdriver
③ Insert the wiring box to the main housing, and use M6x12 screws (4pcs)
to attach the wiring box to the inverter housing. (see Figure 3-11)
Tool: No. 10 Wrench, torque value of 2.8N.m
Figure 3-11 Installation of the wiring box
CAUTION:
The total weight of the CPS SCA20/25KTL-DO series inverter is
about 55kg (≈122 pounds).
Please ensure the mounting is properly installed before hanging the
the inverter on the bracket.
(5) Attach the main housing and the wiring box to the mounting bracket with
the M5x10 bolts (6 pcs). (see Figure 3-12)
Tool: No.2 Phillips head screwdriver, torque value of 1.6N.m
21
