5.4.7 System protection parameters setup

Press DOWN and ENT at the same time in the main interface and enter
the password (UP -> DOWN -> UP -> DOWN) to access the system protection
parameters setup menu. This menu includes 5 submenus: "1 SysPara", "2
Restart", "3 Recover", "4 ClrErrRecd" and "5 Stdset", as shown in Figure 5-15.
Pls Input Pwd
****
Pwd Error
Pls Input Again
****
Wrong Pwd
Figure 5-15 System protection parameter configuration
(1) The system protection parameters of each grid standard can be set up
in "1 SysPara" menu. Please refer to Chapter 5.4.8.
(2) "2 Restart" menu: If a fault shutdown happens, a severe fault may
have occurred inside the inverter. The user can perform a force reboot for one
time in this menu if the user needs to restart the inverter.
→1 SysPara.
2 Restart
3 Recover
4 ClrErrRecd
5 StdSet
1 GridVProtect
2 GridFProtect
3 ON/OFF
4 PowerContr
5 LVRTSet
6 OtherProtect
Are You Sure?
Initialization?
FaultOperated
Success
ClearErrors?
Failure
Success !
1 VDE0126-1-1
2 VDE4105
3 G59
4 C10_11
5 CEI_021
6 IEEE1547
7 BDEW
69
Restarting..
Recovering..
Success !
Failure
Failure!
FaultOperated
Success !
Failure!
