Figure 3-6 Secure the mounting bracket
(3) Hang the inverter onto the mounting bracket as shown in Figure 3-7 and
Figure 3-8;
Lift mounting: Take out the lifting eye nut M10 (2pcs) from the
accessory kit, and screw them on the bolts at the top of the inverter. Use
sling rope or bar (inserted through both lifting eye nuts) to lift the inverter
onto the bracket. The minimum angle between the two sling ropes
should be less than 90 degrees.
Manual mounting: Two people grab the handle positions marked in the
Figure 3-8, and mount the inverter onto the bracket.
CAUTION:
The main housing of the CPS SCA20/25KTL-DO series inverter is
about 46.5kg (≈102.5 pounds).
Please ensure the mounting is properly installed before hanging
the the inverter on the bracket. It is recommended to have at least
18
