3.3.2 AC and ground connection

The following describes how to connect the AC output cables and PE
cable between the inverter and the AC grid:
1) Use the 3mm Hex screwdriver to screw off the 4 screws on the wiring
box and take off the cover. (see Figure 3-28)
Figure 3-28 Take off the cover of the wiring box
2) The inverter supports 3 kinds of cable connection on the AC side
Figure 3-26 Unplug the positive connector
Figure 3-27 Unplug the negative connector
