  • Page 1 High-Speed Positioning System (HSPS) UPH Series...
  • Page 2 Operation Manual...

  • Page 3: Table Of Contents

    Language Menu 12.2 Display Setup Menu 12.2.1 Area Parameters Menu 12.2.2 Changing the Edit Text Menu 12.2.3 Display Parameters 12.3 Motion Parameters Menu 12.3.1 Speed Menu 12.3.2 Limits 12.3.3 Preset/Patrol/Autopan Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 4 Lens Modules Parameters and Area Masking 12.4.2 Infrared Parameters 12.4.3 Illuminator/Dinion Configuration 12.5 Load Default Configuration 12.6 Setup Info Menu Keyboard Commands List - Bosch 13.1 Keyboard Commands List - Pelco 13.2 Changing the Settings 13.3 Changing the Numeric Fields On-screen Display (OSD) Troubleshooting 15.1...

  • Page 5: Safety

    Legal Information Copyright This manual is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
  • Page 6 Servicing - Do not attempt to service this unit yourself. Opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 7: Important Notices

    13. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.
  • Page 8 Quick stops, excessive force, or uneven surfaces may cause the cart/unit combination to overturn. Mount the unit per the manufacturer's instructions. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 9 Electronic Surveillance - This device is intended for use in public areas only. U.S. federal law strictly prohibits surreptitious recording of oral communications. Environmental statement - Bosch has a strong commitment towards the environment. This unit has been designed to respect the environment as much as possible.
  • Page 10 The system ground is only used to comply with safety standards or installation practices in certain countries. Bosch does not recommend connecting system ground to safety ground unless it is explicitly required. However, if the system ground and safety ground are connected and grounding loops are causing interference in the video signal, use an isolation transformer (available separately from Bosch).

  • Page 11: Customer Support And Service

    Connecting System ground to Safety ground may result in ground loops that can disrupt the CCTV system. Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of lost digital information, Bosch Security Systems recommends multiple, redundant recording systems, and a procedure to back up all analog and digital information.

  • Page 12: Unpacking

    Verify that all the parts listed in Parts List, page 12 are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service.
  • Page 13 When the UPH loses power, depending on how it is positioned, the unit may drop slightly forward or backward. Therefore, failure in correctly positioning the UPH before disconnecting the power supply may result in personal injury or possible damage to the device. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 14: Description

    (HSPS) Description The Bosch High-Speed Positioning System is a complete, high-performance, high quality solution that can pan 360 degrees continuously at speeds of up to 100 degrees per second. An extensive range of options lets you tailor the system to your specific requirements. For example, a wide variety of video cameras and lenses, including the optimized Dinion 2X camera and zoom lens combinations, are available.

  • Page 15: Installing The Camera/Lens

    (NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1), ® and all applicable local codes. Bosch Security Systems, Inc. accepts no liability for any damages or losses caused by incorrect or improper installation. Note: For models that already have the camera/lens installed, go to Installing the High Speed Positioning System, page 20.
  • Page 16 Place the desiccant bag inside the housing as shown in the figure below, with the desiccant bag secured into position by the metal fixing accessory and two fixing screws (supplied in the Desiccant accessory bag). 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 17: Preparing The Camera

    Figure 4.4: Attach Desiccant Bag Reference # Description Bracket Desiccant Bag Preparing the Camera Remove the camera packaging material. Make sure that the gasket is present and in good condition. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 18: Connecting The Camera And Motorized Lens

    J2 location on the board. Connect the 2-pin power cable from the camera to the mating connector from the J26 location on the board. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 19 Wrap one of the 102 x 2.5 mm tie wraps around the zoom and focus cable and the coax cable, near the location where the cables connect to the board. Close and secure the housing lid. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 20: Installing The High Speed Positioning System

    Electrical Code (NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1), ® and all applicable local codes. Bosch Security Systems, Inc. accepts no liability for any damages or losses caused by incorrect or improper installation. Notice! The High-speed Positioning System device cannot be mounted upside down! This configuration stresses bearings and mechanical components;...
  • Page 21 300 mm (12 in.) in back of the device is required to facilitate component removal and installation. The device should be installed vertically. Any other position could impair the performance of the device. Do not attach the device upside down. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 22 UPH mountings to any surface. Attach the optional wall or pole mount according to the specific mounting manual. Part Description MTC-PUPH Outdoor Pole Mount for UPH Series MTC-WUPH Outdoor Wall Mount for UPH Series MTC-POLE-W Pole Adapter for MTC-WUPH...
  • Page 23 Apply thread locker (such as Loctite 243) on the holes of the screws. Secure the base to the wall or pole mount with the screws and washers (supplied). Tighten the screws to 4 N m using a calibrated torque wrench. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 24: Wiring The Device

    Make a group with all signal cables and fix them with the tie thread. See the illustration below for a proper cable connection. Note: IR360 version boards will vary slightly because the signals connector has 16 lines as instead of 19, as shown below. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 25: Wiring The Video Cable

    Route the incoming coaxial cable with a male BNC connector into the base and connect to the female BNC connector on the coaxial termination cable. Move the shield to cover the coaxial connection. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 26: Connecting The Power Supply

    The base with power supply box is available in three (3) power supply voltages (24 VAC, 120 VAC, or 230 VAC). To connect the power supply, follow these steps: 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 27 120 / 230 VAC Terminal Connection Blue Neutral Brown Live/Active Green/Yellow Earth 2. Use the appropriate junction box to connect the power supply line. Use a Class 2, UL listed power supply Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 28 Wiring RS-422/Pelco D In order to change the Baud Rate, the 4-way dip switch must be used. Refer to Pelco D Baud Rate, page 43. Figure 5.9: Connecting for RS-422 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 29 RS485-2 A, connect to Pelco controller out Tx + RS485-2 B, connect to Pelco controller out Tx - RS485-1 A, connect to Pelco controller input Rx + RS485-1 B, connect to Pelco controller input Rx - Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 30: Connecting To The Standard Base

    AL1, AL2, AL3, and AL4, COM Alarm inputs 1-4, voltage-controlled (10-35 VDC supplied externally), referred to common COM Warning! The installation is type TNV-1. Do not connect it to SELV circuits. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 31: Connecting To The Ir360 Base

    VDC or 30 VAC @ 1A) AL1 and AL2 Alarm inputs 1-2, voltage-controlled (10-35 VDC supplied externally), referred to AGND AGND Alarm Ground & External IR probe common External photosensor/IR probe Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 32: Fixing The Top Unit

    Push down to snap into place. Apply thread locker (such as Loctite 243) on the holes of the screws. Attach the top unit to the base using the attachment screws and screw seals (supplied). 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 33 Place on or near the device the safety label (supplied) that warns of moving parts. The camera should appear as in the figure below. Assembled High Speed Positioning System (with tabs aligned) Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 34: Assembling And Connecting Ir360 Models (Optional)

    | Assembling and Connecting IR360 Models (optional) (HSPS) Assembling and Connecting IR360 Models (optional) The device must be configured to mount two of the Bosch UFLED illuminators. The illuminators are connected to the bracket supplied with the pan and tilt motor. Caution! For operational reasons, both spotlights must be fitted.

  • Page 35: Fitting The Spotlights On The Bracket

    Fix the assembly using the screw and it washer. Make sure the spotlight is secured firmly to the bracket. Complete the necessary wiring. Configure the on-screen menu to disable complete rotation of the pan and tilt. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 36: Connecting The Spotlights

    Connecting the Spotlights Connecting the Infrared LED Spotlights Open the housing. Extract the support plate from the housing. Disconnect the flat cable. Disconnect the relay power supply connector. Remove the screws. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 37 Connecting the Power Cable Connect the power cable to each spotlight. Figure 9.5: Connecting the Power Cable to the Spotlight Thread the cable through the holes in the pan and tilt bracket. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 38 Insert the cable in the cable glands mounted in the lower part of the housing so that they protrude about 20 cm. Figure 9.7: Inserting the Cable through the Cable Glands Place the desiccant bag in the housing. Figure 9.8: Inserting the Desiccant Bag 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 39 The day/night mode relay is pre-wired. The figure below is for reference only. For more information on how to operate the day/night mode, please call Technical Support at 1-800-326-1450. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 40 High-Speed Positioning System en | Assembling and Connecting IR360 Models (optional) (HSPS) Figure 9.10: Switching Day and Night Mode Reference Description Night Mode 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 41: Making Connections For The Pump Of The Washer Kit (Optional)

    Making Connections for the Pump of the Washer Kit (Optional) The Bosch Washer Kit (pump and water reservoir tank) is an optional product, available separately from Bosch, that connects directly to the High Speed Positioning System in order to clean dirt and debris that accumulates on the glass in front of the lens of the camera, improving visibility through the camera.

  • Page 42: Configuring The Device

    Verify that the position of the DIP switches are the same as in, page 42. Figure 11.1: Positioning the DIP Switches Reference Description Pelco D Baud Rate Not Used, All Off Address RS485 Terminations Biphase + Bilinx 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 43: Pelco D Baud Rate

    You can set the address for the UPH address using the Address switched (see item 3 in , page 42). Notice! The highest addres using the Bosch OSRD protocol is 998. The highest address using the Pelco D protocol is 255. Binary code is used to select the address using the 10 DIP switches. The up position represents binary value “1”, while the down position represents binary value “0”.

  • Page 44: Rs485 Line Termination

    Dip-switch 1 is used to enable the line termination of a Biphase serial line. – Down/ON = terminated. Up/OFF = open (daisy chain). – Dip-switch 2 is used to select the video format (Down/ON = PAL, Up/OFF = NTSC). 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 45: Connections

    All versions support Bilinx and Biphase telemetry control, i.e.: PTZ. The PTZ menu setup of UPH Series is done via the AUX ON - 200 - Enter. The camera menu setup is done via two different AUX commands, i.e.: AUX ON - 46 - Enter (Dinion main menu) and AUX ON - 801 - Enter (Dinion installation menu).
  • Page 46 1 IntuiKey Keyboard 4 LTC 8016 Bilinx Data Interface 2 RS-485 5 Bilinx/Video 3 Allegiant Matrix Switcher 6 UPH Series: unitized pan/tilt head Figure 11.5: Typical Connections to a DiBos DiBos 8 Biphase UPH Series: unitized pan/tilt head Video output coax 2013.11 | 5.2 | F.01U.291.981...
  • Page 47 High-Speed Positioning System Configuring the Device | en (HSPS) Figure 11.6: VIPX1 Connection Diagrams Vidos, IE, DiBos 8, Bosch VMS or equivalent RS-485-2 Ethernet Video UPH Series: unitized pan/tilt head VIP X1 Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 48: Configuring The System

    The Display Setup menu is used to define settings for the information that is permanently displayed on the screen. DISPLAY SETUP MENU > 1 - PAN/TILT POSITION 2 - PRESET TITLE 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 49: Area Parameters Menu

    Focus to store that value. Repeat the process, but put +120.00 in the right column (stop position of text removed from the screen). Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 50 STRING AREA MENU Enables the user to edit a customized, on- Area 1 to screen text message that is activated when Area 8 the device reaches a defined, horizontal position. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 51: Changing The Edit Text Menu

    The character being edited flashes and the joystick (up and down) can be used to change it. After making the change, confirm and continue to edit the text, or else exit with the Iris button. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 52: Display Parameters

    > 1 - OSD VIDEO ENABLING 2 - VIDEO CHAR TYPE : 000 3 - HORIZONTAL DELTA : 000 4 - VERTICAL DELTA : 000 5 - ADDRESS NUMBER 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 53: Motion Parameters Menu

    2 - TILT SPEED > 3 - SPEED 3... 3 - ZOOM PROP. SPEED 4 - SPEED 4... 10.0 5 - SPEED 5... 20.0 6 - SPEED 6... 30.0 Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 54 (pan & TILT SPEED 4 0.1-40.0 tilt); each level corresponds TILT SPEED 5 0.1-40.0 to a defined speed which can be modified by the user. TILT SPEED 6 10.0 0.1-40.0 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 55: Limits

    1 > PAN LIMITS 2 - START PAN 0.00 3 - END PAN 0.00 4 - TILT LIMITS 5 - START TILT 0.00 6 - END TILT 0.00 9 - RAMP TYPE Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 56: Preset/Patrol/Autopan

    > 1 - PRESET > 2 - SPECIAL PRESET PARAM. > 3 - HOME POSITION > 4 - PATROL > 5 - AUTOPAN > 8 - MOTIONS RECALL > 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 57 Description Default Options Moves a camera on a horizontal axis. -180.00° to +180.00° TILT Moves a camera on a vertical axis. -40.00° to +90.00° ENABLE Enables preset. YES, NO Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 58 : 20.0 3 - TILT SPEED REDUC. : 100 6 - PRST DWELL TIME :00005 7 - FORCE PRST DW.TIME 8 - FORCE PRST SPEED Table 12.5: Special Preset Parameters 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 59 The Patrol menu is a defined path from preset to preset. This can be from two (2) presets up to 250. For example, the random option allows various presets such as preset 4, then preset 1, then preset 8, then preset 3. PATROL MENU Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 60 > 1 - START POSITION : 0000 2 - END POSITION : 0000 3 - REACH SPEED : 10.0 4 - FORWARD SPEED : 10.0 5 - REVERSE SPEED : 20.0 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 61 (in seconds); by default the dwell is 50 seconds. MOTIONS RECALL MENU 1 - TIME ENABLING 2 - MOTION TYPE : HOME 3 - DWELL BEFORE : 00050 ACT. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 62: Wiper-Washer

    It is necessary to set a preset position corresponding to the spray which is loaded when the “wiper” function is started. Figure 12.2: Wiper-washer Function WIPER-WASHER MENU > 1 - ENABLED 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 63: Alarms

    2 - NR. 3 - PRESET/PATROL/AUTOPAN " 4 - WIPER-WASHER 4 - SHOW MESSAGE " 5 - ALARMS 5 - DURATION : 00000 6 - TXT: Test Alarm 1 Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 64: Camera/Infrared Parameters

    3, and 4; either ON or OFF status (not user selectable). 12.4 Camera/Infrared Parameters This section covers the lens module options, area masking, and the infrared parameters menu. 12.4.1 Lens Modules Parameters and Area Masking MODULE PARAMETERS 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 65 4 - AREA 4 + 0.00 + 0.00 5 - AREA 5 + 0.00 + 0.00 6 - AREA 6 + 0.00 + 0.00 7 - AREA 7 + 0.00 + 0.00 Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 66: Infrared Parameters

    Telemetry input of illuminator 2 as shown. Set the trip threshold of the two (2) illuminators (see , page 66). This is the preferred configuration when using the INTERNAL sensors. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 67: Load Default Configuration

    DEFAULT VALUES MENU 1 - LOAD DEF. VALUES? 2 - DELETE ALL PRST? ATTENTION!!! RELOAD ALL SETTINGS EXCEPT FOR PRESETS The Load Default menu is used to load the default settings. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 68: Setup Info Menu

    BOSCH xx ver. BOSCH xx mm/dd/yy mm/dd/yy HD r.x HD r.x Protocol : BOSCH Baudrate : 38400 Address : 00001 Enabled RS485 : TX-RX FWInt xx FWCam: xx 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 69: Keyboard Commands List - Bosch

    High-Speed Positioning System Keyboard Commands List - Bosch | en (HSPS) Keyboard Commands List - Bosch Setup and Configuration Open OSD configuration: AUX ON - 200 - Enter Dinion main menu on: AUX ON - 46 - Enter Dinion installation menu on: AUX ON - 801 - Enter...

  • Page 70: Changing The Settings

    Changing the Settings To change a setting, follow these steps: AUX ON - 200 - Enter to enable the OSD using Bosch protocol (Bilinx or Biphase connection); Pelco protocol (RS485-2 connection) uses 95 - PRESET. Move the cursor to the parameter to be changed.

  • Page 71: On-Screen Display (Osd)

    Table 14.1: Accessing the Main Menu - AUX On 200 MODE ENHANCE COLOR MODE ID TRAFFIC DEFAULTS EXIT Table 14.2: Accessing the DinionXF camera Setup Menu - AUX On 46 (screen may differ depending on the camera type) Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 72 High-Speed Positioning System en | On-screen Display (OSD) (HSPS) Notice! Based on the model you are using, on-screen menus may vary slightly. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 73: Troubleshooting

    (down position) the “PROGRAM.” dip version with the message, position). switch (dip-switch number 1 in the Dip-switch upgrade ON. Factory Use section) and then switch the device on again. Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 74: Low And High Temperatures

    (FPN) on the video signal. Solution: via Bilinx change the SensUp setting in the camera to OFF; this reduces the number and intensity of the blemishes. 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 75: Dimensions And Range Of Movement

    High-Speed Positioning System Troubleshooting | en (HSPS) 15.2 Dimensions and Range of Movement 258 (10.16) 514 (20.24) Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 76 High-Speed Positioning System en | Troubleshooting (HSPS) 514 (20.24) (2.87) Figure 15.1: Dimensions and Range of Movement 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.

  • Page 77: Maintenance

    Refer to , page 77, Item 2, above for fuse locations. Voltage Fuse F1 Fuse F2 24 VAC 50/60 Hz T 4A L 250 V T 8A H 250 V Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...

  • Page 78: Appendix A: Wiring Summary

    Alarm 2 Input; triggered by external DC voltage External IR Probe, Normally Open Contact AGND Alarm Ground & External IR probe common Output 1; Normally Open; Dry contact relay output 2013.11 | 5.2 | F.01U.291.981 Operation Manual Bosch Security Systems, Inc.
  • Page 79 Peclo D protocol, 300 to 19200 Baud 8 N 1 Rx channel Data (connect to Pelco controller output TX +) Data (connect to Pelco controller output TX -) Biphase + (OSRD protocol) Biphase - (OSRD protocol) Bosch Security Systems, Inc. Operation Manual 2013.11 | 5.2 | F.01U.291.981...
  • Page 82 Bosch Security Systems, Inc. 850 Greenfield Road Lancaster, PA, 17601 www.boschsecurity.com © Bosch Security Systems, Inc., 2014...
