  • Page 1 AUTODOME IP starlight 5000i IR NDP‑5512‑Z30L User Manual...

  • Page 3: Table Of Contents

    AUTODOME IP starlight 5000i IR Table of contents | en Table of contents Introduction Systems requirements Establishing the connection Password protection in camera System overview Live page Configuration Playback Dashboard Operation via the browser Live page 3.1.1 Connection 3.1.2 3.1.3 Pre-positions 3.1.4...
  • Page 4 | Table of contents AUTODOME IP starlight 5000i IR Encoder Profile Encoder Streams Encoder Regions 6.10 Encoder Statistics 6.11 Privacy Masks 6.12 Picture Settings 6.13 Lens Settings 6.14 PTZ Settings 6.15 Pre-positions and Tours 6.16 Pre-position mapping 6.17 Sectors 6.18...
  • Page 5 AUTODOME IP starlight 5000i IR Table of contents | en 10.1 Maintenance 10.2 Licenses 10.3 Certificates 10.4 Logging 10.5 Diagnostics 10.6 System Overview AUX Commands Troubleshooting 12.1 Rebooting the unit 12.2 Physical reset button 12.3 Customer Service and Support Bosch Security Systems User Manual 2019.11 | 1.2 |...

  • Page 6: Introduction

    If you cannot connect, the unit may have reached its maximum number of connections. Depending on the device and network configuration, each unit can have up to 50 web browser connections, or up to 100 connections via Bosch Video Client or Bosch Video Management System.

  • Page 7: Password Protection In Camera

    AUTODOME IP starlight 5000i IR Introduction | en Password protection in camera The device is password-protected. The first time that any user accesses the device, the device will prompt the user to set a password at the service level. The camera requires a strong password. Follow the prompts in the dialog box, which specifies what is required.

  • Page 8: System Overview

    Click this icon to configure the device. Dashboard Click this icon to see detailed system information. Links Click this icon to navigate to the Bosch download store. Click this icon to get context-sensitive help for the page you are browsing. Live page The Live page is used to display the live video stream and control the unit.

  • Page 9: Dashboard

    AUTODOME IP starlight 5000i IR System overview | en Dashboard The Dashboard page is used to display detailed information about the device. The Dashboard is only visible in the application bar if the Show 'Dashboard' option is enabled by a service-level user in the Configuration -> Web Interface -> Appearance page.

  • Page 10: Operation Via The Browser

    | Operation via the browser AUTODOME IP starlight 5000i IR Operation via the browser Live page 3.1.1 Connection Stream 1 Select this option to display stream 1 of the camera. Stream 2 Select this option to display stream 2 of the camera.

  • Page 11: Aux Control

    AUTODOME IP starlight 5000i IR Operation via the browser | en 3.1.4 AUX Control With the tab AUX Control you can enter pre-programmed keyboard control commands. These commands are composed of a command number plus the appropriate function key (Show pre- position, Set pre-position, AUX on, or AUX off).

  • Page 12: Recording Status

    | Operation via the browser AUTODOME IP starlight 5000i IR The OSD displays the message, “Auto Focus: ONE PUSH.” Nightmode Click this button to activate/deactivate night mode for the camera. After a few seconds, the camera switches modes. Custom tour Click this button to view (in continuous playback) a custom tour that was previously configured.

  • Page 13: Status Icons

    AUTODOME IP starlight 5000i IR Operation via the browser | en If you hover over the middle icon, the CPU load is shown. If you hover over the right-hand icon, the network load is shown. This information can help with problem solving or when fine tuning the unit. For example: –...

  • Page 14: Selecting The Recording Stream

    | Operation via the browser AUTODOME IP starlight 5000i IR 3.2.1 Selecting the recording stream On the left side of the browser, expand the Connection group if necessary. To view a recording stream: Click the Recording drop-down arrow to see the options.

  • Page 15: General

    A check mark in this check box indicates that at least one certificate is loaded onto the camera. If no certificates are loaded, then “No certificate installed” appears to the right of the text. The Escrypt certificate is a root certificate for Bosch Security Systems that proves that the device meets the following criteria: –...

  • Page 16: Date/Time

    | General AUTODOME IP starlight 5000i IR – user is the middle authorization level. At this level you can operate the device, play back recordings, and also control camera, for example, but you cannot change the configuration. – live is the lowest authorization level. At this level you can only view the live video image and switch between the different live image displays.

  • Page 17: Display Stamping

    AUTODOME IP starlight 5000i IR General | en First, check the time zone setting. If it is not correct, select the appropriate time zone and click Set. Click Details to edit the DST table. Select the region or the city which is closest to the system's location from the list box below the table.
  • Page 18 | General AUTODOME IP starlight 5000i IR Logo position Select the position for the logo on the OSD: To the left of the name, To the right of the name, or Logo only. Select Off (the default value) to disable logo positioning.

  • Page 19: T 28181

    AUTODOME IP starlight 5000i IR General | en The fields Position (XY) and (0...255) appear. In the field Position (XY), specify the exact position. (The default is 10.) In the field (0...255), enter the position range. (The default is 176).
  • Page 20 | General AUTODOME IP starlight 5000i IR Enable Select this checkbox to enable the system to use the other parameters on this page in accordance with the GB/T 28181 national standard. H.264 elementary stream Select this checkbox to select or to enable the H.264 elementary stream.

  • Page 21: Web Interface

    AUTODOME IP starlight 5000i IR Web Interface | en Web Interface Appearance You can adapt the appearance of the web interface and change the website language to meet your requirements. GIF or JPEG images can be used to replace the company and device logos. The image can be stored on a web server (for example, http://www.myhostname.com/images/logo.gif).

  • Page 22: Live Functions

    | Web Interface AUTODOME IP starlight 5000i IR Show VCA items Shows alarm fields, lines and routes configured for the video analytics in the following colors: – Green: Fields, lines and routes used in a task are displayed in green. They can be edited but not deleted.

  • Page 23: Camera

    AUTODOME IP starlight 5000i IR Camera | en Camera Installer Menu Base frame rate Select the base frame rate for the camera. Note: Shutter times, frame rates, and the analog output (if present) are affected by this value. Notice! Changing the field Sensor mode A change to the parameter in the field Sensor mode requires approximately 10-20 seconds to complete.

  • Page 24: Picture Settings

    | Camera AUTODOME IP starlight 5000i IR – Color Only (Traffic) In this mode, the camera does not switch to monochrome mode at low light levels. The mode is optimized to minimize motion artifacts and to capture the color of vehicles/pedestrians and traffic lights, even at night, for scenarios such as city surveillance and traffic monitoring.

  • Page 25: Enhance

    AUTODOME IP starlight 5000i IR Camera | en To set the Maximum gain level, select Low, Medium or High from the drop-down box. AE-response speed Select the speed of the response of auto exposure. Options are Super slow, Slow, Medium (default), Fast.

  • Page 26: Scene Mode Scheduler

    | Camera AUTODOME IP starlight 5000i IR Sharpness level This field is active when Sharpness mode is set to Manual. Adjust the level of sharpness of the video image (from 1 to 15) using the slider. Adjustments to the Sharpness level appear on the OSD.
  • Page 27 AUTODOME IP starlight 5000i IR Camera | en Apply white balance Click Hold to put ATW on hold and save the current color settings. The mode changes to manual. The table below identifies the options available in the field White balance and the additional fields that appear depending on the options selected.

  • Page 28: Alc

    | Camera AUTODOME IP starlight 5000i IR R-gain In Manual white balance mode, adjust the red gain slider to offset the factory white point alignment (reducing red introduces more cyan). G-gain In Manual white balance mode, adjust the green gain slider to offset the factory white point alignment (reducing green introduces more magenta).

  • Page 29: Enhance

    AUTODOME IP starlight 5000i IR Camera | en Enhance High dynamic range Select On to activate wide dynamic range, which improves image reproduction in extreme high-contract scenes. Select Off to deactivate the feature. – Auto - Stabilization activates automatically when the camera detects vibration greater than the set threshold.
  • Page 30 | Camera AUTODOME IP starlight 5000i IR You can change individual parameter values of a profile and you can also change the name. You can switch between profiles by clicking the appropriate tabs. Caution! The profiles are rather complex. They include a large number of parameters that interact with one another, so it is generally best to use the default profiles.
  • Page 31 AUTODOME IP starlight 5000i IR Camera | en Expert settings If necessary, use the expert settings to adapt the I-frame quality and the P-frame quality to specific requirements. The setting is based on the H.264 quantization parameter (QP). I-frame distance Use the slider to set the distance between I-frame to Auto or to between 3 and 255.

  • Page 32: Encoder Streams

    | Camera AUTODOME IP starlight 5000i IR Encoder Streams Note: If you access this menu while the camera is recording, the following message appears at the top of the page: Recording is currently active. Therefore, for ‘Current profile’ the respective stream profile selected for recording is displayed for information.

  • Page 33: Encoder Statistics

    AUTODOME IP starlight 5000i IR Camera | en From the last drop-down box (the unlabeled Mode selection list), select the encoder quality for the defined area. (The drop-down box has the default option of Default). For unimportant parts of the video image, select Background.

  • Page 34: Picture Settings

    | Camera AUTODOME IP starlight 5000i IR Notice! Draw the mask at 50% optical zoom or less for improved masking performance. Draw the mask 10% larger than the object to ensure that the mask completely covers the object as the camera zooms in and out.
  • Page 35 AUTODOME IP starlight 5000i IR Camera | en 5.2.1.2 Exposure and gain control Gain control Adjusts the automatic gain control (AGC). – AGC (default): Automatically adjusts the gain to the lowest possible value needed to maintain a good picture. –...

  • Page 36: Lens Settings

    | Camera AUTODOME IP starlight 5000i IR 6.13 Lens Settings Focus speed Use the slider (from 1 to 8) to control how fast the Auto focus will readjust when the focus becomes blurred. IR focus correction Optimizes the focus for IR lighting. Options are: On, Off (default).

  • Page 37: Pre-Positions And Tours

    AUTODOME IP starlight 5000i IR Camera | en Click the View Control link, under the image cameo, to access the directional and zoom controls. Use the View Control dialog box to make the necessary camera movements. Click the Stop Recording button to save all actions.

  • Page 38: Pre-Position Mapping

    To stop the tour, type 8 and click AUX off. 6.16 Pre-position mapping Pre-position mapping allows you to map a function to a pre-position action. This feature works for Bosch protocols and for non-Bosch protocols. Action Select the appropriate action: Show or Set. Pre-position Enter the number of the pre-position to map.

  • Page 39: Sectors

    Enter a number between 0000 and 9999, inclusive, to identify the camera. 6.19 Illuminator Note: This menu page is valid for AUTODOME IP 5000i IR and AUTODOME IP starlight 5000i IR only. IR mode By default, the camera is set to automatic illuminator mode (Auto). To deactivate this mode, select Off.

  • Page 40: Audio

    | Camera AUTODOME IP starlight 5000i IR IR Operation Range Select the zoom factor or range for the IR light: – 1X-30X (default) – 10X-30X – 15X-30X – 20X-30X The focal length of the lens determines the intensity level of the illuminator. The more the camera zooms in, the more power is put on the IR near and far.

  • Page 41: Recording

    The Storage overview field displays the local media. Note: The recording performance of the SD card depends on the speed (class) and the performance of the SD card. Bosch recommends an SD card of Class 6 or higher. Bosch Security Systems User Manual 2019.11 | 1.2 |...

  • Page 42: Activating And Configuring Storage Media

    | Recording AUTODOME IP starlight 5000i IR Note: For more information about Automatic Network Replenishment (ANR), refer to the White Paper “ANR 2.0 Automatic Network Replenishment (ANR),” available on the product page for your camera. Access the product page on the online product catalog from http:// www.boschsecurity.com/corporate/product-catalog/index.html.
  • Page 43 AUTODOME IP starlight 5000i IR Recording | en Stream profile settings Select the encoder profile setting that is to be used with stream 1 and 2 when recording. This selection is independent of the selection for live stream transmission. (The properties of the encoder profiles are defined on the Encoder Profile page.)

  • Page 44: Maximum Retention Time

    | Recording AUTODOME IP starlight 5000i IR – Video loss Select the Virtual alarm sensors that are to trigger a recording, via RCP+ commands or alarm scripts, for example. Maximum Retention Time Recordings are overwritten when the retention time entered here has expired.

  • Page 45: Recording Status

    AUTODOME IP starlight 5000i IR Recording | en Activating the Recording After completing configuration you must activate the recording scheduler and start the recording. Once recording is underway, the Recording Profiles and Recording Scheduler pages are deactivated and the configuration cannot be modified.

  • Page 46: Sd Card Status

    | Recording AUTODOME IP starlight 5000i IR Target Select the target—the name of the account on the server—to which to save images. When face recognition is available, selected images of the face can be sent to a target account.

  • Page 47: Alarm

    AUTODOME IP starlight 5000i IR Alarm | en Alarm Alarm Connections You can select how the camera responds to an alarm. In the event of an alarm, the unit can automatically connect to a pre-defined IP address. You can enter up to ten IP addresses to which the camera will connect in sequence in the event of an alarm, until a connection is made.
  • Page 48 | Alarm AUTODOME IP starlight 5000i IR Remote port Depending on the network configuration, select a browser port here. The ports for HTTPS connections will be available only if the On option is selected in the SSL encryption parameter.

  • Page 49: Video Content Analysis (Vca)

    A separate Help file provides information about configuring for the VCA settings. Note: Full VCA configuration and Help is only available on the web browser when MPEG ActiveX software from Bosch is installed on your computer. MPEG ActiveX software is available from the Bosch Security Systems DownloadStore (https://downloadstore.boschsecurity.com/) To open the VCA Help in the web browser: Select Configuration >...
  • Page 50 | Alarm AUTODOME IP starlight 5000i IR Tamper detection Detect tampering of cameras and video cables by means of various options. Run a series of tests at different times of the day and night to ensure that the video sensor is operating as intended.

  • Page 51: Audio Alarm

    AUTODOME IP starlight 5000i IR Alarm | en Scene too bright Activate this function if tampering associated with exposure to extreme light (for instance, shining a flashlight directly on the lens) should trigger an alarm. Use the slider to set the threshold of the alarm trigger.

  • Page 52: Alarm Task Editor

    | Alarm AUTODOME IP starlight 5000i IR SMTP user name Enter a registered user name for the chosen mailserver here. SMTP password Enter the required password for the registered user name here. Format You can select the data format of the alarm message.

  • Page 53: Alarm Rules

    AUTODOME IP starlight 5000i IR Alarm | en Enter new scripts in the Alarm Task Editor field or change existing scripts in line with your requirements. When finished, click Set to transmit the scripts to the device. If the transfer was successful, the message Script successfully parsed.

  • Page 54: Network

    | Network AUTODOME IP starlight 5000i IR Network The settings on these pages are used to integrate the device into a network. Some changes only take effect after a reboot. In this case Set changes to Set and Reboot.
  • Page 55 AUTODOME IP starlight 5000i IR Network | en IPv6 Consult with the network administrator before making changes to this section. IP address Enter the desired IP address for the camera in this field. The IP address must be valid for the network.

  • Page 56: Dyndns

    | Network AUTODOME IP starlight 5000i IR Min. TLS version Select the version for minimum Transport Layer Security (TLS). HSTS Select this option to use the web security policy HTTP Strict Transport Security (HSTS) to provide secure connections. RCP+ port 1756 To exchange connection data, you can activate the unsecured RCP+ port 1756.

  • Page 57: Advanced

    This field identifies any cloud-based services with which the camera communicates. – If you have registered the device on a cloud-based service such as Bosch Remote Portal, then this field identifies this fact (“Registered on Bosch Remote Portal”). Note: The button (Connect to Bosch Remote Portal) to connect to the device with that service is active.

  • Page 58: Network Management

    | Network AUTODOME IP starlight 5000i IR Password Enter the password that is stored in the RADIUS server. TCP port The device can receive data from an external TCP sender, for example an ATM or POS device, and store it as metadata. Select the port for TCP communication. Select Off to deactivate the TCP metadata function.

  • Page 59: Multicast

    AUTODOME IP starlight 5000i IR Network | en When the Universal Plug-and-Play (UPnP) function is activated, the unit responds to requests from the network and is automatically registered on the requesting computers as a new network device. This function should not be used in large installations due to the large number of registration notifications.

  • Page 60: Image Posting

    | Network AUTODOME IP starlight 5000i IR Notice! Duplication of data places a heavy demand on the unit and can lead to impairment of the image quality under certain circumstances. Port Assign a different port to each data stream if there are simultaneous data streams at the same multicast address.

  • Page 61: Accounts

    AUTODOME IP starlight 5000i IR Network | en Timeout Fill in the timeout in seconds. Leave at 0 for no timeout. Maximum image width [px] Fill in the maximum image width in pixels. Leave at 0 for automatic width selection.

  • Page 62: Service

    | Service AUTODOME IP starlight 5000i IR Service 10.1 Maintenance Update server The address of the update server appears in the address box. Click Check to make a connection to this server. Select the appropriate version for your camera to download the firmware from the server.

  • Page 63: Certificates

    AUTODOME IP starlight 5000i IR Service | en 10.3 Certificates Add a certificate/file to the file list Click Add. In the Add certificate window choose either: – Upload certificate to select a file that is already available: – Click Browse to navigate to the required file.

  • Page 64: Aux Commands

    | AUX Commands AUTODOME IP starlight 5000i IR AUX Commands Function Command Description On/Off AutoPan without limits (Continuous) On/Off Auto Pan between limits On/Off Run Custom Pre-Position Tour On/Off Run Pre-Position Tour On/Off AutoPivot Enable On/Off Backlight Compensation (BLC)

  • Page 65: Troubleshooting

    Transmission mode is set to UDP. Camera reboots frequently or Test your camera with another power supply. intermittently. Check the Bosch website for a software update that might address the issue. No OSD messages appear. Bosch’s Video SDK is required. Video management software from third parties does not use the SDK.

  • Page 66: Rebooting The Unit

    If you cannot control the unit after the firmware upgrade, then cycle the power to the unit. If a power reset does not solve the problem, or if Configuration or video management software identifies the unit as “Videojet Generic,” then contact your Bosch Service Center for an RMA for the unit.

  • Page 67: Physical Reset Button

    Search again for the IP address. Access the camera using the web browser. Set the initial password for the camera. For AUTODOME IP 5000i IR │ AUTODOME IP starlight 5000i IR models, the reset button is near the SD card slot. To access the reset button, remove the metal cover installed on the back of the camera.

  • Page 68: Customer Service And Support

    | Troubleshooting AUTODOME IP starlight 5000i IR 12.3 Customer Service and Support If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Telephone: 800-366-2283 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com Customer Service...
  • Page 69 AUTODOME IP starlight 5000i IR Troubleshooting | Bosch Security Systems User Manual 2019.11 | 1.2 |...
  • Page 70 | Troubleshooting AUTODOME IP starlight 5000i IR 2019.11 | 1.2 | User Manual Bosch Security Systems...
  • Page 72 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2019...
