Basic System Commands; Basic Touchpad Commands Table; Testing Zones/Sensors - GE Concord 4 Series Installation Instructions Manual

Note
While the sensor test is a
valuable installation and ser-
vice tool, it only tests sensor
operation for the current
conditions. You should per-
form a sensor test after any
change in environment,
equipment, or programming.
Note
If you hear a long, low-
pitched beep, proceed to the
following section "If a Wire-
less Sensor Does Not Test."
71

Basic System Commands

Table 8 describes basic touchpad operating commands. For complete details on system operation,
including user programming, refer to the system User's Manual.
Command
* (STATUS)
* + *
1 + CODE
2 + CODE
3 + CODE
2 (quick arm on)
3 (quick arm on)
2 or 3 + CODE + 4
or
2 or 3 + 4
5 + 2 or 3 + CODE
or
5 + 2 or 3
7 + 1
7 + 2
7 + 4
7 + 6
7 + 7 + n (n = output number [1–6])
1–2 = onboard outputs
3–6 = module outputs
8 + CODE + 2
8 + CODE + 3
8 + installer CODE + 3
8 + CODE + 6
8 + CODE + 8
0 + 0
0 + n (n = light number 1-9)

Testing Zones/Sensors

Test sensors/zones after all programming is completed, whenever there is a change in environ-
ment, equipment, or programming, and whenever a zone- or sensor-related problem occurs.
If the system does not respond as described in the following procedure, see the "Troubleshoot-
ing" section.
1. Place all sensors and zones in their non-alarm state.
2. At an alphanumeric touchpad, enter the sensor test mode by pressing 8 + installer code + 3.
The touchpad sounds one beep and displays
timer.
3. Trip each zone/sensor one at a time. Touchpads (and interior sirens) should sound one short,
high-pitched beep and the display should show the sensor name (or number) and
4. Press the button when you think all zones/sensors are tested. The touchpad displays
STATUS
any untested sensors/zones and touchpad panics. If all sensors/zones and touchpad panics
have been tested, the display shows
5. Test any untested zones/sensors and touchpad panics.
6. The system stays in sensor test mode for 15 minutes. When less than 5 minutes remain,
touchpads and interior sirens beep and the panel announces the remaining time over the
speakers once every minute. After 15 minutes the panel disarms to OFF, automatically. If
you need more time to complete the sensor test, press 8 + installer CODE + 3 while the sys-
tem is still in sensor test mode. This restarts the 15 minutes of test time.
WWW.DIYALARMFORUM.COM
Table 8: Basic Touchpad Commands
Indicates current system status
Indicates AC power, battery, and current system
status
Disarms system to OFF
Arms system to STAY
Arms system to AWAY
Arms system to STAY
Arms system to AWAY
Arm system—No Delay (no exit or entry delay)
Arms system silently (no arming status beeps)
Turns chime feature on and off
Turns Energy Saver on and off
Partition jump without entering code (only if Parti-
tion Security option is off)
Identifies alarms in memory
Turns the output on or off. (This command is only
functional after output text is entered into panel
memory.)
Initiates a phone test
Initiates a sensor test
Initiates a dealer sensor test
Partition jump
View Event History
Turns all controlled lights on and off
Turns individual controlled light on and off
SENSOR TEST
SENSOR TEST OK
System Response
. The panel starts a 15 minute
.
Concord 4 Series Systems
.
OK
