Connect all necessary output wiring using the Installation Instructions included with the module.
Input
I D : X X X X X X X X
1 2 3 4 5 6 7 8 9 1 0 1 1 1 2 1 3 1 4 1 5 1 6
G N D + 1 2 V
3 4

SuperBus 2000 Cellular Backup Module

Connect the SuperBus 2000 Cellular Backup Module to the SuperBus 2000 2 Amp Power Sup-
ply and panel as shown in Figure 23.
!
Since the SuperBus 2000 Cellular Backup Module draws more than 1 amp, it must be
powered by the SuperBus 2000 2 Amp Power Supply and not the panel.
Caution
2 4 V A C 2 4 V A C
WWW.DIYALARMFORUM.COM
A B U S B
5 6
Figure 22. Wiring Input and Output Modules to the Panel
+ 1 2 V
+ 1 2 V B U S A B U S B
G N D G N D Z O N E G N D
O U T
Figure 23. Wiring the Cellular Backup Module to the Panel
Output
I D : X X X X X X X X
1 2 3 4 5 6 7 8 9 1 0 1 1 1 2 1 3 1 4 1 5 1 6 1 7 1 8
G N D + 1 2 V
3 4
1 2 3 4 5 6
SuperBus 2000
2 Amp Power
Supply Terminals
A B U S B
5 6
