The DAO_DATA3/XMTA S/PDIF output pin on the CS48540 and CS48520 can be configured as:
• S/PDIF Transmitter - Sent configuration from
A soft reset is required when switching between any of the above modes.
DAO_DATA3/XMTA
DS734UM7

Table 6-9. S/PDIF Transmitter Pins

Pin Name
S/PDIF Audio Output A

Table 6-10. S/PDIF Transmitter Configuration

Description
Enable S/PDIF Audio Output A on
DAO_DATA3/XMTA
Copyright 2009 Cirrus Logic, Inc.
Table 6-10
Pin Description
Hex Message
0x8100001e
0x00005080
§§
Digital Audio Output Port Description
CS485xx Hardware User's Manual
LQFP-48 Pin
Pin # Type
29 Output
6-10
