Introduction

CS485xx Hardware User's Manual
8.1 Introduction
The CS485xx has up to 19 GPIO pins available for system control functions. In order to fit the most
functionality possible into a small package, all of the GPIOs are multiplexed with other audio and control
ports on the CS485xx. This means that the number of GPIOs available to a given system depends on how
many of the pins are being used for audio functionality.
The GPIOs are also a crucial part of the Watchdog Timer implementation. One GPIO can be dedicated as a
watchdog alarm to indicate when the timer has expired.

8.2 GPIO Description

Table 8-1 identifies the GPIO pins available on the CS485xx.
Pin Name
8-1
Table 8-1. Digital Audio Output (DAO) Pins
Example Multiplexed Audio
GPIO0 DAI1_DATA1
GPIO1 DAI1_DATA2
GPIO2 DAI1_DATA3
GPIO3 DAO1_DATA1
GPIO4 DAO1_DATA2
GPIO5 DAO1_DATA3
GPIO6 DAO2_DATA0
GPIO7 DAO2_DATA1
GPIO8
GPIO9 SCP_MOSI
GPIO10 SCP_MISO
GPIO11
GPIO12
GPIO13
GPIO14 DAI2_LRCLK
GPIO15 DAI2_SCLK
GPIO16 DAI1_DATA0
GPIO17 DAI2_DATA0
GPIO18 DAO_MCLK
Copyright 2009 Cirrus Logic, Inc.
General Purpose Input/Output Pins
LQFP-48
Function Pin #
SCP_CS
SCP_CLK
SCP_IRQ
SCP_BSY
Chapter 8
Pin
Type
11 I/O
13 I/O
14 I/O
27 I/O
26 I/O
29 I/O
31 I/O
32 I/O
38 I/O
34 I/O
35 I/O
36 I/O
39 I/O
41 I/O
17 I/O
18 I/O
10 I/O
15 I/O
25 I/O
DS734UM7
