SPI Port
CS485xx Hardware User's Manual
Pin Name
SPI Chip Select, Active Low
In serial SPI slave mode, this pin is used as the active-low chip-select
SCP_CS
input signal. In SPI serial master mode, if this pin is driven low by
another master device on the bus, it will cause a mode fault to occur.
SPI Control Port Bit Clock
SCP_CLK In master mode, this pin serves as the serial control clock output. In
serial slave mode, this pin serves as the serial control clock input.
SPI Mode Master Data Output/Slave Data Input
SCP_MOSI SCP_MOSI in SPI slave mode this pin serves an the data input, in SPI
master mode this pin serves as the data output.
SPI Mode Master Data Input/Slave Data Output
SCP_MISO In SPI slave mode this pin serves as the data input. In SPI master
mode this pin serves as the data output.
Serial Control Port Data Ready Interrupt Request Output, Active Low
This pin is driven low when the DSP has a message for the host to
SCP_IRQ read. The pin will go high when the host has read the message and the
DSP has no further messages. This pin reflects the state of the SCP
port Transmit Buffer Empty Flag.
Serial Control Port Input Busy, Output, Active Low
SCP_BSY This pin is driven low when the control port's receive buffer is full. This
pin reflects the state of the SCP or PCP Receive Buffer Full Fag.
EE_CS Master Mode Serial EPROM Chip Select, Active Low

3.3.1 SPI System Bus Description

The SPI bus is a multi-master bus. This means that more than one device capable of controlling the bus can
be connected to it. Generation of clock signals on the SPI bus is always the responsibility of master devices;
each master generates its own clock signals when transferring data on the bus. Bus clock signals from a
master cannot be altered by any other device on the bus, otherwise a collision will occur. The slave chip-
select signals can only be controlled by master devices.
SCP_MOSI (Master Out/Slave In) and SCP_MISO (Master In/Slave Out) are bidirectional lines that change
their behavior depending on whether the device is operating in master or slave mode. Only the master can
drive the MOSI signal while only the slave can drive the MISO signal.
3-14

Table 3-2. Serial Control Port SPI Signals

Pin Description
Copyright 2009 Cirrus Logic, Inc.
LQFP-48 Pin
Pin # Type
38 Input
36 I/O
34 I/O
35 I/O
Open
39
Drain
Open
41
Drain
41 Output
