PCI-DAS6052 User's Guide

Accuracy

333 kS/s sampling rate, single channel operation and a 15-minute warm-up. Accuracies
listed are for measurements made following an internal calibration. They are valid for
operational temperatures within ±1°C of internal calibration temperature and ±10°C of
factory calibration temperature. Calibrator test source high side tied to Channel 0 High
and low side tied to Channel 0 Low. Low-level ground is tied to Channel 0 Low at the
user connector.
Range
±10V
±5V
±2.5V
±1V
±500mV
±250mV
±100mV
±50mV
0 to 10V
0 to 5V
0 to 2V
0 to 1V
0 to 500mV
0 to 200mV
0 to 100mV
Table 6-1. Absolute Accuracy
Absolute Accuracy
±15.6 LSB
±5.7 LSB
±15.6 LSB
±15.7 LSB
±15.9 LSB
±18.0 LSB
±21.0 LSB
±23.0 LSB
±8.1 LSB
±27.8 LSB
±28.0 LSB
±28.0 LSB
±31.7 LSB
±36.4 LSB
±38.7 LSB
6-2
