PCI-DAS6052 User's Guide

DAQ-Sync Connector and Pinout

Connector type
Compatible cable
Signal Name
DS A/D START TRIGGER
DS A/D STOP TRIGGER
DS D/A START TRIGGER
14-pin Ribbon Cable
Details on the CDS-14-x cable are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=104&pf_id=1528.
Table 2- 4. DAQ-Sync Connector and cable types
14-pin right-angle 100 mil box header
MCC p/n: CDS-14-x, 14 pin ribbon cable for board-to board DAQ-Sync
connection; x = number of boards (Figure 2-3 shows a CDS-14-3 cable)
Table 2-5. DAQ-sync connector pinout (view from top)
DS A/D CONVERT
DS D/A UPDATE
RESERVED
SYNC CLK
2
14
13
Figure 2-3. CDS-14-3 cable
Pin
Pin
1
■ ■
2
3
■ ■
4
5
■ ■
6
7
■ ■
8
9
■ ■
10
11
■ ■
12
13
14
■ ■
1
2
1
14
13
2-11
Installing the Board
Signal Name
GND
GND
GND
GND
GND
GND
GND
The red stripe
identifies pin # 1
2
1
14
13
