Functional Details

Basic architecture

Figure 4-1 on page 4-4 is a simplified block diagram of the PCI-DAS6052. This board
provides all of the functional elements shown in the figure.
The System Timing and Control (STC) is the logical center for all DAQ, DIO, and DAC
(if applicable) operations. It communicates over two major busses: a local bus and a
memory bus.
The local bus carries digital I/O data and software commands from the PCI Bus Master.
There are two Direct Memory Access (DMA) channels provided for data transfers to the
PC.
Primarily, the memory bus carries A/D and D/A related data and commands. There are
three buffer memories provided on the memory bus:
The queue buffer (8K configuration memory) stores programmed channel numbers,
gains, and offsets.
The ADC buffer (8K FIFO [First In, First Out]) temporarily stores scanned and
converted analog inputs.
The DAC 16K buffer stores data to be output as analog waveforms.
Auxiliary input & output interface
The board's 100-pin I/O connector provides six software-selectable inputs, and three
software-selectable outputs. The signals are user-configurable clocks, triggers and gates.
Refer to the
their timing requirements.
Table 4-1 lists all of the possible signals and the default signals you use on the nine pins.
"DAQ signal timing" on page 4-5 for information about these signals and
