Range
±10V
±5V
±2.5V
±1V
±500mV
±250mV
±100mV
±50mV
0 to 10V
0 to 5V
0 to 2V
0 to 1V
0 to
500mV
0 to
200mV
0 to
100mV
1. Averaged measurements assume averaging of 100 single-channel readings
Table 6-2. Absolute Accuracy Components – All values are (±)
% of Offset
Reading (µV)
0.0371 947
0.0071 476
0.0371 241
0.0371 99.2
0.0371 52.1
0.0421 28.6
0.0471 14.4
0.0471 9.7
0.0071 476
0.0371 241
0.0371 99.2
0.0371 52.1
0.0421 28.6
0.0471 14.4
0.0471 9.7
Noise +Quantization
(µV)
Single Pt Averaged
981 87.0
491 43.5
245 21.7
98.1 8.7
56.2 5.0
32.8 3.0
22.4 2.1
19.9 1.9
491 43.5
245 21.7
98.1 8.7
56.2 5.0
39.8 3.0
22.4 2.1
19.9 1.9
6-3
Specifications
Absolute
Temp Drift
Accuracy at
(%/DegC)
FS (mV)
1
0.0006 4.747
0.0001 0.876
0.0006 1.190
0.0006 0.479
0.0006 0.243
0.0006 0.137
0.0006 0.064
0.0006 0.035
0.0001 1.232
0.0006 2.119
0.0006 0.850
0.0006 0.428
0.0006 0.242
0.0006 0.111
0.0006 0.059
