PCI-DAS6052 User's Guide

DAQ-Sync inter-board Triggers/Clocks

The DAQ-Sync bus provides inter-board triggering and synchronization capability. Five
trigger/strobe I/O pins and one clock I/O pin are provided on a 14-pin header. The
DAQ-Sync signals use dedicated pins. Only the direction may be set.
DAQ-Sync Signals:

Power Consumption

+5V
+5V available at I/O connector
Environmental
Operating Temperature Range
Storage Temperature Range
Humidity
Mechanical
Card dimensions
DS A/D START TRIGGER
DS A/D STOP TRIGGER
DS A/D CONVERT
DS D/A UPDATE
DS D/A START TRIGGER
SYNC CLK
1.25 A typical, 1.5A max. Does not include power consumed
through the I/O connector.
1A max, protected with a resettable fuse
0 to 55°C
-20 to 70°C
10 to 90% non-condensing
PCI half card: 174.4mm(L) x 106.9mm(W) x11.65mm(H)
6-13
Specifications
