PCI-DAS6052 User's Guide
Configurable AUXIN<5:0>, AUXOUT<2:0> External
Trigger/Clocks
The PCI-DAS6052 provides nine user-configurable Trigger/Clock pins available at the
100-pin I/O connector. Of these, six are configurable as inputs while three are
configurable as outputs.
AUXIN<5:0> Sources
(SW selectable)
AUXOUT<2:0> Sources
(SW selectable)
Default Selections:
Compatibility
Edge-sensitive polarity
Level-sensitive polarity
Minimum pulse width
A/D CONVERT:
A/D TIMEBASE IN:
A/D START TRIGGER:
A/D STOP TRIGGER:
A/D PACER GATE:
D/A START TRIGGER
D/A UPDATE:
D/A TIMEBASE IN:
STARTSCAN:
SSH:
A/D STOP:
A/D CONVERT:
SCANCLK:
CTR1 CLK
D/A UPDATE
CTR2 CLK
A/D START TRIGGER:
A/D STOP TRIGGER:
A/D PACER GATE:
D/A START TRIGGER:
AUXIN0:
AUXIN1:
AUXIN2:
AUXIN3:
AUXIN4:
AUXIN5:
AUXOUT0:
AUXOUT1:
AUXOUT2:
5V/TTL
Rising/falling, software selectable
Active high/active low, software selectable
3.75nS
6-12
External ADC convert strobe
External ADC pacer time base
ADC Start Trigger
ADC Stop Trigger
External ADC gate
DAC trigger/gate
DAC update strobe
External DAC pacer time base
A pulse indicating start of conversion
Active signal that terminates at the
start of the last conversion in a scan.
Indicates end of scan
ADC convert pulse
Delayed version of ADC convert
CTR1 clock source
D/A update pulse
CTR2 clock source
ADC Start Trigger Out
ADC Stop Trigger Out
External ADC gate
DAC Start Trigger Out
A/D CONVERT
A/D START TRIGGER
A/D STOP TRIGGER
D/A UPDATE
D/A START TRIGGER
A/D PACER GATE
D/A UPDATE
A/D CONVERT
SCANCLK
