DAQ-Sync Connector and Pin Out
Connector type
Compatible cables
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14

Main Connector and Pin Out

Connector type
Compatible Cables
Compatible accessory products
(with C100HD50-x cable)
Compatible accessory products
(with C100MMS-x cable)
14-Pin right-angle 100mil box header
MCC p/n: CDS-14-x, 14 pin ribbon cable. x = number of boards (2 - 5)
Signal Name
DS A/D START TRIGGER
GND
DS A/D STOP TRIGGER
GND
DS A/D CONVERT
GND
DS D/A UPDATE
GND
DS D/A START TRIGGER
GND
RESERVED
GND
SYNC CLK
GND
Shielded SCSI 100 D-Type
C100HD50-x, unshielded ribbon cable. x = 3 or 6 feet
C100MMS-x, shielded round cable. x = 1, 2, or 3 meters
ISO-RACK16/P
ISO-DA02/P
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
