Appendix B — Electrical Specifications
Power: 4.0 Watts (max.)
5VDC +/– 5%, 200 mV p-p max. ripple, 554 mA @ 5VDC (typ.)
Optional Int: 10-28V Accy
Host Connector / Pin Assignments
High Density 15 Pin D-sub Socket Connector
Pin
Host RS-232
1
2
TxD
3
RxD
4
5
6
RTS
7
8
9
10
CTS
11
12
13
14
15
a. Can sink 10 mA and source 10 mA.
b. The default is activated by connecting pin 8 to ground pin 4.
c. Chassis ground: Used to connect chassis body to earth ground only. Not to be used as power or signal return.
Direct Input / Output Diagrams
MS-4X Imager User's Manual
Host/Aux RS-232
Power +5 VDC
TxD
RxD
Power/Signal Ground
NC
Aux TxD
Output 1 TTL a
Default configuration b
Trigger
Aux RxD
Output 3 TTL a
New Master (NPN)
Chassis ground c
Output 2 TTL a
NC
Host RS-422/485
TxD(–)
RxD(–)
TxD(+)
RxD(+)
Appendices
In/Out
In
Out
In
Out
Out
In
In
In
Out
In
Out
A-5
