Start Trigger Character (Non-Delimited)

Usage: Useful in applications where different characters are required to start a
read cycle.
Definition: A single ASCII host serial trigger character that starts the read cycle and is
not enclosed by delimiters such as
Non-delimited Start characters can be defined and will function according
to the trigger event.
When defining Start trigger characters, the following rules apply:
• In External Edge the imager looks only for the Start trigger character
• In External Level the Start trigger character begins the read cycle and
• In Serial Data or External Edge trigger mode, either a Start trigger
Serial Cmd: <K229,start
Default: NUL
Options: Two hex digits representing any ASCII character except XON and XOFF.
Important: The ASCII characters <, >, and
For <: <K229h,3C>
For >: <K229h,3E>
,
For : <K229h,2C>
See ASCII Character Entry Modifier
characters as hex values.
MS-4X Imager User's Manual
and ignores any Stop trigger character that may be defined.
the Stop trigger character ends it. Note that even after a symbol has
been decoded and the symbol data transmitted, the imager remains in
External Level trigger read cycle until a Stop character is received.
character or a hardware trigger can start an edge trigger read cycle.
character>
(00 in hex) (disabled)
for a detailed explanation of how to enter ASCII
< and >.
,
can only be entered as hex pairs:
Read Cycle
5-13
