Symbol Quality Separator/Data Matrix Output Mode

Symbol Quality Separator/Data Matrix Output Mode

Symbol Quality Separator applies to both Symbol Quality groups: ISO/IEC 16022 Symbol
Quality Output and Microscan Symbol Quality Output.
Symbol Quality Separator
Definition: Inserts a separator between each enabled field of the symbol quality output.
Serial Cmd: <K708,symbol quality
Default: <SP>
Options: Any ASCII character.
Important: The ASCII characters <, >, and
For <: <K708h,3C>
For >: <K708h,3E>
,
For : <K708h,2C>
See ASCII Character Entry Modifier
characters as hex values.
Symbol Quality Separator by ESP
8-8
separator,output mode>
(space character)
for a detailed explanation of how to enter ASCII
,
can only be entered as hex pairs:
When you double-click on the
default separator SP, the Symbol
Quality Separator Calculator
appears. Use the calculator keypad
for one-click separator configuration.
MS-4X Imager User's Manual
