5.2.3 Peer-to-Peer (P2P) Connection

This PBX automatically establishes peer-to-peer communication between peer-to-peer compatible IP

extensions (i.e., IP-PTs and SIP extensions) and SIP Trunks that belong to the same P2P group. With

peer-to-peer calls, the call is routed directly from one IP extension to another without going through a DSP

card, which means that P2P calls are established without using the PBX's resources.

P2P Scenarios

P2P calls can be established between telephones in a single site or across sites. The following illustrations

show P2P calls established in a variety of network configurations. It is assumed that all the devices are

connected over a private IP network.

P2P connection within a site

Calls between IP telephones within a site establish a P2P connection.
