Figure 5. Recovery Jumpers - Silicon Graphics Altix XE210 User Manual

2
3
J1D2
2
3
Jumper Name
CMOS Clear
Password Clear
BMC Force Update Mode
8
BMC Force
Update Mode
Disable
2
Password
Enable
Reset
3
J1D1
Clear
CMOS
J1D3
If pins 2-3 are jumpered, the CMOS settings will be cleared on the
next reset. These pins should be jumpered on 1-2 for normal
operation.
If pins 2-3 are jumpered, administrator and user passwords will be
cleared on the next reset. These pins should be jumpered on 1-2
for normal operation.
If pins 2-3 are jumpered, BMC Force Update Mode is enabled.
These pins should be jumpered on 1-2 for normal operation.

Figure 5. Recovery Jumpers

Jumper Purpose
® ®
SGI Altix XE210 User's Guide
TP02080
