Setting The Alarm; Setting Motion Detection - KGuard Security Easy Link EL421 User Manual

Chapter 5: KGUARD Web Client

5.5.5 Setting the Alarm

Use the Alarm menu to select when to trigger the alarm and choose the alarm notification, such as buzzer sound,
email, or full screen notification.

Setting Motion Detection

1
On the Main Menu, click Remote Setting.
2
On the left panel, click Alarm > Motion. The Motion screen appears.
3
On Channel, select the channel where you want to setup motion detection.
4
Check the Enable box to enable motion detection.
5
By default, the whole screen is marked for motion detection (red block).
6
To disable motion detection on an area, click a block and then drag the mouse to highlight the scope that you want
to unmark (gray block). Or, click Clear to unmark all areas and then select a new area to mark for motion detection.
DVR User's Manual
96
Area is marked for motion
detection
Area is unmarked for motion
detection
