1.5 Remote Control

4-Channel / 8-Channel DVR

No. Icon
1 1 ~ 8
2 9, 0
3 ALL
4 MENU
5 SEL
6
7
8
Audio/
9
Search
10 Mute
11
12
13
14
15
16
1 2
1
4 5
7 8
3
0
ALL
5
7 SEL
8
9
AUDIO/
SEARCH
11
14
15
Description
Numeric keys
Press to display channel 1 ~ 8.
Numeric keys
Press "0" key to lock or unlock the current screen.
Press to display all channels.
Press to enter or exit the Main Menu.
Press to enter the selected menu item and edit the setting.
Press to move up in the OSD menu.
Press to move left or right in the OSD menu.
Press to move down in the OSD menu.
In Playback mode, press to turn the audio on or off.
Press to search for recorded video.
Press to turn mute on or off.
Press to rewind during video playback.
Press to play recorded video or enter the recording search menu.
Press to fast forward during video playback.
Press to start manual recording.
Press to pause the video playback or enter frame-playback mode.
Press to stop manual recording or stop the video playback.
Chapter 1: Product Overview
3
6
2
9
4
MENU
6
7
10
MUTE
12
13
16
DVR User's Manual
