Chapter 5: KGUARD Web Client

5.5.4 Setting the Network Configuration

You can use the Network menu to setup how the DVR connects to the network. It provides 3 network connection
options: Static IP, DHCP, and PPPoE.
Note:
Consult your network administrator or the Internet Service Provider (ISP) to determine the type of connection you are
using and the required parameters to complete the setup.

Network Settings

To configure the network settings, do the following:
1
On the Main Menu, click Remote Setting.
2
On the left panel, click Network > Network. The Network screen appears.
• DCHP: With Dynamic Host Configuration Protocol
(DHCP) service, your router will automatically assign
an IP address to your computer connected to the
network.
• Static IP: This network protocol allows you to
configure the network interface using a fixed IP
address.
3
Specify the Client Port and HTTP Port numbers.
• Client Port: Specify the port number that the device will use to send DVR command and video stream.
• HTTP Port: Specify the port number that you will use to log in to the device.
Note:
• Obtain these information from your network administrator or your Internet Service Provider (ISP).
DVR User's Manual
90
• PPPoE: The Point-to-Point Protocol over Ethernet
(PPPoE) is a network protocol for encapsulating
Point-to-Point Protocol (PPP) frames inside Ethernet
frames. This network protocol allows the device to
be directly connected using a DSL modem.
