5.2 The Interface

After you login to KGUARD Web Client, the Live screen appears.
Note:
The number of channels displayed may vary depending on the DVR model. The illustration below is from a
16-channel DVR.
1
2
3
No. Item
1 Main Menu
2 Channel Controls
3 Display Screen
4 Display Controls
5 PTZ Controls
4
Description
Click a menu item to access. Options are:
• Live: Allows you to view the Live screen, control PTZ view, and manage recording
and playback options. See
• Playback: Allows you search, playback, and download recorded videos. See
Searching and Playing Recorded Videos" on page
• Remote Setting: Allows you to configure the DVR remotely. See
Settings" on page 84.
• Local Setting: Allows you to specify the local disk drive location to save recorded
videos, captured screen shots, and downloaded videos.
• Logout: Click to logout from KGUARD Web Client.
Lists all channels that can be connected to the DVR.
The icons of each channel are used to manage the channel, see
Recording" on page 80.
Displays the channels in grid mode or full screen mode. To manage the display screen,
see "5.3.1 Switching Screen Modes" on page
Controls for playback, recording and switching screen modes.
Manages the PTZ speed dome. See
Chapter 5: KGUARD Web Client
"5.3 Live Viewing" on page 78.
82.
78.
"5.3.3 Using PTZ Controls" on page
5
"5.4
"5.5 Remote
"5.3.2 Viewing and
81.
DVR User's Manual
77
