5
If you want to modify the user name, enter desired name in User Name.
6
Click the Password box to enter the password. Then, click Apply.
7
Click OK.

3.6.4 Pop-up Menu

With the Pop-up menu, you can access to the main menu and other common features. To bring up the Pop-up Menu,
click on the right mouse button or press the MENU button on the remote control. The available Pop-up menu items
vary depending on the current setting or operation.
1
No. Connector
1 Main Menu
Lock
2
3 View 4
4 View 9
5 View 16
6 PTZ
7 Start / Stop Cruise
8 Zoom
9 Record Search
10 Start / Stop Record
11 Start / Stop Rotate
PIP 1x1
12
13 PIP 1x2
14 Audio
2 3 4 5 6
Description
Access the OSD menu and adjust the DVR settings.
Lock access to enter the OSD menu. You need to type the user name and password
before entering the OSD menu. See
Switch to a 4-window display. See
Switch to a 9-window display.
Switch to a 16-window display.
Use the PTZ control. See page
Start/stop cruise of the PTZ camera. See
Enable zoom. See page 37.
Search for recorded videos to play back. See
Start/stop manual recording. See
Start/stop rotation of channel display. See
View one channel in full screen with another channel enclosed in a small window. See
page 34.
View one channel in full screen with two other channels enclosed in small windows.
Turn off or turn on the audio.
7 8 9 10 11
page 30.
page 34.
36.
page 37.
page 45.
page 38.
page 35.
Chapter 3: Getting Started
12 13 14
