Chapter 4: Using the DVR
6
After all settings are complete, click Apply.
7
When data saving is complete, click OK.

4.4.3 Email Settings

The DVR supports sending of email notifications when events occur, such as when motion is detected or the HDD fails
at the specified channel, day, and time.
Note:
Be sure that the DVR network connection is properly configured before proceeding with the email setup.
To set up email, do the following:
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu
3
On Email, select Enable.
4
Click Schedule to implement the email schedule. For details, refer to
5
On SSL, select the Enable check box if your email server needs the SSL verification. Check with your email service
provider for the applicable setting.
6
Enter the SMTP port and SMTP Server of the sending email server, the email address and password of the sender in
Sender and Sender PWD respectively.
Note:
By default, the SMTP port is 25 for email without SSL verification. For Gmail server or for email that needs SSL
verification, the SMTP port is 465, by default. Check with your ISP for the correct setting.
7
In Receiver Email, enter the email address where the notification email is to be sent. In Interval, select an email
sending interval.
8
After all settings are complete, click Apply.
9
When data saving is complete, click OK.
DVR User's Manual
54
> NETWORK, select the Email tab.
"Email Schedule Setup" on page 55.
