3.6 The Main Screen

3.6.1 Screen Icons

There are four types of recording indicator on the main screen of each channel.
Channel title
Recording
indicator
8-window display
Icon Description
Motion detector is activated.
M
Hard disk drive memory is full.
H
Cannot detect hard disk drive.
Video recording is in progress.
R
VIDEO LOSS
Video loss.
Current date & time
4-window display
16-window display
Note:
• During recording mode, [
on the screen. If [ ] icon is displayed on the screen, it
M
indicates that motion detection is enabled.
• If the "VIDEO LOSS" appears on the screen, check the
camera connection.
Chapter 3: Getting Started
] icon or [ ] icon appears
R M
