Note:
• Obtain these information from your network administrator or your Internet Service Provider (ISP).
• If you cannot use the either of the two default ports, 80 or 9000, the specified port may be occupied by other
programs or it is being blocked by your service provider. Enter other port number. In this case, you need to
add the port number after the IP address. For example, if you set the HTTP Port as 85, you need to enter the
IP address as "192.168.3.103:85".
5
Enter other parameter settings (if applicable).
• If your network connection is Static, specify the static IP address, Subnet Mask, Gateway, and DNS 1/DNS 2 IP
addresses.
• If your network connection is PPPoE, enter the User Name and Password that you setup with your DSL service
provider. Then, specify the DNS 1/DNS 2 IP addresses.
Note:
The system supports two DNS server input options: DNS Server1 for main server and DNS Server2 for sub server.
Please contact your local ISP (Internet Service Provider) to obtain the correct DNS Server parameter.
6
To enable Auto Port Forwarding (UPNP) feature, select Enable.
Note:
Not all routers support the Auto Port Forwarding feature. If this function does not work, you must manually open
the ports in your router.
7
After all settings are complete, click Apply.
8
When data saving is complete, click OK.

4.4.2 Remote Stream Setup

The Remote Stream page allows you to enable or disable video output of a particular channel if the channel is being
viewed via remote access.
1
In preview mode, right-click on the mouse to display the Pop-up menu.
2
Select Main Menu
displayed on a table.
3
Select the channel and adjust the corresponding settings such as Video, FPS, and Quality.
4
Check the Audio box to enable audio.
5
To copy the current settings to all channels or one specific channel. Click the arrow on Copy and To to select an
option and then click Copy.
> NETWORK, select the Remote Stream tab. The remote stream framerate settings are
